Поз.
Артикул
Описание
5
FUEL TANK70 L.
5
FUEL TANK , Replaced By: A1244700304
23
GAUGE SENDER UNIT70 L
26
FLANGE
29
SEAL RING
32
SEAL RING
38
FUEL STRAINER , Replaced By: A1244700106
38
FUEL STRAINER PARTS KIT
44
SEAL RING
62
WASHER PROTECTIVE PLATE TO BRACKET,5 502998
68
NUT SWITCH TO FLOOR PLATE
71
BOOT LEFT
74
BOOT RIGHT
77
PAD FUEL TANK,FRONT SIDE, 020 008805 023 010290 026 002881 120 012502 123 005628 126 006101 130 009362
80
PAD FUEL TANK BOTTOM SIDE
83
VALVE , 003,004,080,083 NOT FOR RETROFIT/CATALYST VEHICLES
83
VALVE , 003,004,080,083 NOT FOR RETROFIT/CATALYST VEHICLES
86
BOOT , 003,004,080,083 NOT FOR RETROFIT/CATALYST VEHICLES
89
HOSE ***
89
HOSE , Replaced By: A2019970852
92
LOOM TIE
95
GROMMET FILLER NECK THRU FENDER RECESS
113
FILLER CAP , WITH LOCK UNDEFINED
116
FILLER CAP , Replaced By: A0004700730
119
SEAL RING
122
GUIDE SIGN DIESEL REFILLING
122
GUIDE SIGN , Replaced By: A1245840246
122
GUIDE SIGN , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A2105849217
125
PROTECTIVE COVER , Replaced By: A1244781237
125
PROTECTIVE COVER , USED WITHOUT AUTOMATIC LOCKING DIFFERENTIAL (A S D)
125
PROTECTIVE COVER LIMITED-SLIP DIFFERENTIAL CONTROL VALVE
128
NUT COVERING TO CAB FIRE WALL
131
HOSE , ORDER BY THE METER 107.022 005201 ALSO INSTALLED ON 005190-005192,005194-005199. 107.023 012497 107.024 021804 ALSO INSTALLED ON 021794,021804
