Поз.
Артикул
Описание
5
INTAKE MANIFOLD , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 216579/91, Replaced By: A3641415701
5
ELBOW , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 246422/92, Replaced By: A3640985315
5
INTAKE MANIFOLD
5
INTAKE MANIFOLD
5
ELBOW (CHARGING AIR ELBOW),296411/93
92
ELBOW (CHARGING AIR ELBOW)
99
CHARGING AIR INTERCOOLER
99
CHARGING AIR INTERCOOLER ,945734
99
CHARGING AIR INTERCOOLER ,945733, Replaced By: A3660980620, +001A3660981280
106
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3660982180
106
GASKET
106
GASKET CHARGING AIR INTERCOOLER
106
GASKET CHARGING AIR INTERCOOLER,945734
113
COVER REAR
120
SEAL RING REAR
120
SEAL RING VALVE
120
SEAL RING , Replaced By: A0189974848
127
COVER FRONT
134
SEAL RING FRONT
141
GASKET , Replaced By: A3660981680
141
GASKET COVER TO CHARGE AIR ELBOW
148
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
148
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
148
SCREW , Replaced By: N304017008043
148
SCREW , Replaced By: N304017008053
148
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
148
SCREW CLAMP ON BRACKET
148
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
148
SCREW VALVE TO BRACKET M 8X55
162
SUSPENSION EYE ,943612, Replaced By: A3662200241, +001N000931010111
162
SUSPENSION EYE REAR,943613
169
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
176
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
177
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
177
SPRING WASHER , Replaced By: N000137008212
281
SUSPENSION EYE FOR TRANSPORT ONLY,943612
288
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
290
SCREW BRACKET,LEFT AND RIGHT
302
BRACKET FRONT
302
BRACKET FRONT
304
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
309
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
316
WASHER EXHAUST MUFFLER TO STRAP
316
WASHER REAR FOGLAMP TO BRACKET
323
BOLT. SCREW BRACKET TO PUSH ROD CHAMBER COVER
323
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
325
SCREENING PLATE , Replaced By: A3660900334
325
SCREENING PLATE , Replaced By: A3660900634
325
SCREENING PLATE ,234537/92
335
BRACKET SCREENING PLATE, FROM ENGINE 234538 YEAR OF MANUFACTURE 1992 UP TO ENGINE 351138 YEAR OF MANUFACTURE 1994
345
SCREW RELAY VALVE TO BRACKET
355
WASHER EXHAUST MUFFLER TO STRAP
355
WASHER , Replaced By: N000125008443
999
NUT
999
NUT
999
SCREW BRACKET TO CONSOLE
999
SCREW CLUTCH OPERATION,4 282707
999
NUT , Replaced By: N304032010002
999
NUT , Replaced By: N304032008006
999
SCREW SUPPORT TO MOUNTING PLATE,D 180260
999
SCREW SUPPORT TO SIDE MEMBER M 10X65,B 884219
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW PLUG
999
SCREW PLUG OIL FILLING
999
WASHER , Replaced By: N000125008443
999
SUSPENSION EYE
999
GASKET
999
INTAKE MANIFOLD
999
INTAKE MANIFOLD
999
ELBOW
999
MANIFOLD (CHARGING AIR ELBOW)
999
CONNECTING PIPE FROM TURBOCHARGER TO CHARGING AIR ELBOW
999
ELBOW
999
CHARGING AIR INTERCOOLER , NOT USED
999
SUSPENSION EYE , NOT USED
999
SUSPENSION EYE
999
INTAKE MANIFOLD
999
INTAKE MANIFOLD , NOT USED
999
INTAKE MANIFOLD
999
ELBOW
999
ELBOW
999
ELBOW (CHARGING AIR ELBOW), NOT USED
999
SUSPENSION EYE
999
SEAL RING , Replaced By: A0279977948
