Поз.
Артикул
Описание
6
STEERING BOX
10
BUSHING47.1 MM
10
BUSHING REPAIR SIZE I 47.6 MM
14
SEAL RING
14
SEAL RING
18
PLUG , Replaced By: N000906016000
18
SCREW PLUG
22
STEERING NUT , Replaced By: A4064600218
22
STEERING NUT
26
SEAL RING , 032,033,040,041: UP TO CAB 1600091 132,133,140,141: UP TO CAB 1600091
30
BARREL-TYPE BEARING , Replaced By: A3459817006
30
BARREL-TYPE BEARING STEERING WORM, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
30
BARREL-TYPE BEARING
33
STEERG. WORM SECTOR SHAFT
36
BALL CUP
40
SEAL RING
43
OIL LEVEL CHECK PIPE
47
STEERING BOX COVER , Replaced By: A3214600414, +001A0029900251
50
BUSHING STEERING SHAFT BEARING IN COVER, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
53
GASKET , Replaced By: A3524610180
53
GASKET
56
SCREW , Replaced By: N000931008049
59
SCREW
63
SPRING
67
THRUST PIECE
70
THRUST WASHER
73
LOCK
76
SEAL RING
79
NUT ,297463
82
RING
85
SEAL RING
88
SEAL RING
91
NUT , Replaced By: A6743560226
91
GROOVED NUT
94
LOCK
97
NUT
100
PITMAN ARM
104
SCREW STEERING TO STEERING BRACKET
107
SCREW STEERING TO STEERING BRACKET
110
NUT STEERING TO STEERING BRACKET TO 327 990 01 14,322 990 09 14
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
RIVET REAR CROSS MEMBER 12X42 MM
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
SCREW BRACKET TO SIDE MEMBER
999
SNAP RING STEERING SHAFT BEARING IN COVER, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
999
SCREW PLUG OIL FILLING
999
SCREW PLUG STEERING BOX
999
SEAL RING OIL FILLING AND OIL DRAIN
999
NUT , Replaced By: N308673012002
999
SCREW , Replaced By: N304017010002
999
SCREW MOUNTING AND RAIL TO LEAF SPRING
999
LOCK PLATE P.T.O. TO TRANSMISSION
999
COTTER PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN CYLINDER TO BRACKET
999
PITMAN ARM
999
STEERING BOX ASSEMBLY , FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
999
STEERING SHAFT BOTTOM, 001,002,003,021,024 UP TO CHASSIS FB005511 345.001,002,003,021,024,026 FOR VEHICLES WITH HIGH CAB
999
STEERING BOX ASSEMBLY , Replaced By: A3444601201
999
STEERING BOX ASSEMBLY , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3094601501
999
STEERING BOX ASSEMBLY , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A3274606501
999
STEERING WORM , Replaced By: A3094600708, +001N007603030400, +001N007604030100
999
STEERING WORM , Replaced By: A3274600018
999
STEERING BOX COVER ,297463, Replaced By: A3214600514, +001A0029900251
999
STEERING BOX WITH BEARING BUSHING
999
BRACKET
999
STEERING BOX COVER STEERING BOX
999
STEERING BOX COVER
999
STEERING BOX ASSEMBLY , Replaced By: A3084600001
999
STEERING NUT WITH WORM AND INCLINED SELF-ALIGNING ROLLER BEARING
999
STEERING WORM , Replaced By: A3094601018
999
STEERING BOX ASSEMBLY , FOR BREAK-DOWN,SEE UNIT MICROFICHE,MODEL: 762.002 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
BEARING BUSHING O.D., 28.024 BIS 28.036 MM
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
NUT
999
CAPTO 000 464 11 01
999
STEERING WHEEL ,5 057904 NO.8316INO.7C52INO.7B90INO.9051I II I
