Поз.
Артикул
Описание
3
RESERVOIR
5
RESERVOIR BRAKE FLUID RESERVOIR
7
FILLER CAP
8
STRAINERTO 364 431 70 02
9
WASHER
10
NUT CONTROL ARM TO REAR AXLE
11
BRACKET FLUID RESERVOIR
13
SCREW LICENSE PLATE TO BRACKET,4 300861
15
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
17
LINE FROM RESERVOIR TO FITTING 8X0.7 MM, FROM CHASSIS 47019
17
LINE FROM FLUID RESERVOIR TO BRAKE MASTER CYLINDER,FRONT AXLE BRAKE CIRCUIT 8X0.7 MM, UP TO CHASSIS 47018
18
LINE FROM FITTING TO MASTER CYLINDER, FRONT AXLE BRAKE CIRCUIT 8X0.7 MM, FROM CHASSIS 47019
19
LINE FROM FLUID RESERVOIR TO BRAKE MASTER CYLINDER,REAR AXLE BRAKE CIRCUIT 8X0.7 MM
79
LINE FROM BRAKE MASTER CYLINDER TO DISTRIBUTOR, FROM CHASSIS 47019
79
LINE FROM BRAKE MASTER CYLINDER TO DISTRIBUTOR 6X0.7 MM, UP TO CHASSIS 47018
80
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
80
UNION SCREW , Replaced By: A0004280072
83
CLAMP LINE TO SIDE MEMBER
85
SCREW COMPRESSED AIR LINE MOUNTING
87
LOCK WASHER PLUG SOCKET
89
NUT TACHOGRAPH TO BRACKET
91
BRAKE HOSE
91
BRAKE HOSE
91
BRAKE HOSE , Replaced By: A3454287135
91
BRAKE HOSE
91
BRAKE HOSE
95
BRACKET BRAKE HOSE
97
LOCK
99
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
103
DISTRIBUTOR REAR AXLE
103
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
105
BRACKET
107
SCREW POWER CYLINDER TO BEARING BRACKET
109
LOCK WASHER RAIL TO BATTERY SUPPORT
111
NUT LEVER TO SHIFTING SHAFT
113
SCREW BRACKET TO TRANSMISSION CASE
115
WASHER BRACKET AND DISTRIBUTOR TO FRONT AXLE
117
LOCK WASHER RAIL TO BATTERY SUPPORT
119
NUT LEVER TO SHIFTING SHAFT
121
LINE FROM DISTRIBUTOR TO LEFT FRONT WHEEL 6X0.70 MM
122
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
122
UNION SCREW , Replaced By: A0004280072
123
CLAMP LINE TO SIDE MEMBER
124
SCREW COMPRESSED AIR LINE MOUNTING
125
LOCK WASHER PLUG SOCKET
126
NUT TACHOGRAPH TO BRACKET
133
BRAKE HOSE
133
BRAKE HOSE , Replaced By: A3644287335
133
BRAKE HOSE
133
BREMSSCHLAUCH F 380 LANG. BRAKE HOSE FRONT WHEEL BRAKE CYLINDER
143
CONNECTOR RIGHT BRAKE CYLINDER
145
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
147
SEAL RINGTO 000 553 03 05,000 553 18 05,
149
HOLLOW SCREW LEFT AND RIGHT FRONT WHEEL BRAKE LINES
151
NUT , FROM UP TO FRONT AXLE 2219487, FROM FRONT AXLE 2219488 SEE SPARE PARTS LIST 815
153
LINE FROM DISTRIBUTOR TO RIGHT FRONT WHEEL BRAKE HOSE 6X0.7 MM
999
REPAIR KITTO 001 431 98 06
999
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
999
HOLLOW SCREW
999
CONNECTOR
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
SPRING RETAINERTO 000 429 63 44,000 429 59 44
999
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
999
DIAPHRAGMTO 001 429 48 44
999
ELBOW FITTING
999
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
999
VALVE (OVERFLOW VALVE) WESTINGHOUSE
999
999
REPAIR KIT LARGE SCOPE TO 000 434 30 01
999
REPAIR KIT LARGE SCOPE TO 345 431 70 05
999
REPAIR KITTO 000 430 55 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT , Replaced By: A0004304206
999
999
BREATHER PIPETO 001 431 83 05,WABCO
999
PROTECTIVE CAP BRAKE BOOSTER
999
FILLER RINGTO 001 431 83 05,WABCO
999
SEAL RING
999
CUPBOSCH
999
VALVEWABCO,002 0,012 0
999
FILLER CAP
999
PISTONTO 001 431 83 05,WABCO
999
PISTONTO 345 431 71 05
999
PISTONTO 002 431 27 05
999
PISTONTO 002 431 27 05
999
PISTONTO 345 431 70 05
999
CUPTO 000 431 76 14
999
CUP 3/2-WAY VALVE WABCO
999
GASKETTO 000 429 16 30
999
REPAIR KIT , Replaced By: A0004305760
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
SPRING
999
SPRINGWABCO,002 0,012 0
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
FITTING
999
HANDLETO 000 434 23 01
999
HANDLETO 345 430 73 81
999
VALVE (OVERFLOW VALVE) BOSCH
999
VALVE (OVERFLOW VALVE) WABCO
999
VALVE (OVERFLOW VALVE) GRAU
999
REPAIR KIT SMALL SCOPE TO 345 431 70 05
999
REPAIR KIT , Replaced By: A0004304106
999
REPAIR KIT SMALL SCOPE TO 000 434 30 01
999
CUP , Replaced By: A0014312386
999
CUPTO BOSCH-NR.0481 027 104
999
CUP101
999
SPRINGTO BOSCH-NR.0481 027 024
999
SPRINGTO 345 431 70 05
999
SPRINGTO 345 431 70 05
999
SPRINGTO 001 431 83 05
999
SPRINGTO 345 431 71 05
999
PRESSURE REGULATOR"KNORR",FB486598 USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
REPAIR KITBOSCH
999
SPRINGTO 000 429 63 44,000 429 59 44
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
FITTING , Replaced By: A0039978972
999
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
FITTING
999
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
SEAL RING
999
REPAIR KIT SMALL SCOPE TO 345 430 73 81
999
LOCK , Replaced By: N000472060000
999
LOCK , Replaced By: N000472045000
999
LOCK , Replaced By: N000984038000
999
LOCK , Replaced By: N000472047001
999
LOCKTO 345 431 70 05
999
SEAL RING , Replaced By: A0179974148
999
SEAL RING18.72X2.62 MM,WABCO,002 0,012 0
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
WASHER , Replaced By: A3454317076
999
WASHER , Replaced By: A3454317376
999
CUPTO 344 430 73 01
999
CUP , Replaced By: A3454317286
999
PISTON
999
SEAL RING17.12X2.62 MM, 402,407 FROM CHASSIS 657000
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
CLAMP , Replaced By: A3129952420
999
THRUST RING LOCKING VALVE
999
RESERVOIR
999
CLAMP , Replaced By: A1109950401
999
999
CONSOLE
999
CLAMP LINE MOUNTING
999
999
BRACKET HAND-BRAKE/TRAILER-BRAKE COMPRESSEDAIR LINE
999
999
REPAIR KITTO 000 429 28 44
999
CLAMP
999
LOOM TIE. CLAMP HOSE TO HEATING PIPE
999
HOLLOW SCREW DISTRIBUTOR TO MASTER CYLINDER
999
DISTRIBUTORTO 345 430 73 01
999
ELBOW FITTING
999
VALVE , Replaced By: A0004320807
999
WASHERTO 002 430 71 01
999
PRESSURE REGULATOR"WABCO",486597
999
CUPTO 344 430 73 01,002 430 27 01
999
WASHERTO 344 430 73 01,002 430 27 01
999
VALVE"WABCO DO BRASIL", USED WITH AIR BRAKE
999
ELBOW FITTINGTO 28.2.2 R
999
LOOM TIE
999
HOSE BREATHER LINE TO 001 431 83 05
999
BRACKET OIL LINE MOUNTING
999
ELECTRIC CABLE FROM FIRE WALL TO EMERGENCY RELEASE VALVE
999
ROD REAR
999
ROD FROM LEVER TO DOUBLE LEVER, 345.401,402,403,406,407,408 FROM CHASSIS 548304 USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
999
999
999
999
LINE FROM PRESSURE REGULATOR TO FITTING 15X1.5 MM, 364.101,111,152,162 FROM CHASSIS 040196, 364.173 FROM CHASSIS 040207
999
999
999
999
999
ROD , Replaced By: A3584200174
999
ROD REAR, REAR AXLE I,4 272929
999
COVER , Replaced By: A0004312892
999
REPAIR KITTO 000 431 21 14
999
REPAIR KIT , Replaced By: A0034301181
999
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
COTTER PIN STRAP TO SUPPORT
999
WASHER TRAILER PLUG SOCKET TO BRACKET
999
LOCK WASHER , Replaced By: N912004010102
999
SPRING WASHER CABLE TO ALTERNATOR
999
SPRING WASHER CAB FLOOR
999
LOCK RINGTO 345 431 71 05
999
LOCK RING
999
LOCK RING PLANETARY CARRIER
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW BRACKET TO SIDE MEMBER,A 069681
999
SCREW PLUG SOCKET TO FRAME
999
SCREW PISTON ROD TO CLUTCH PEDAL
999
NUT
