Поз.
Артикул
Описание
92
BRACKET FUEL PREHEATING
92
BRACKET FUEL PREHEATING
119
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
119
SCREW CLAMP ON BRACKET
128
WASHER EXHAUST MUFFLER TO STRAP
128
WASHER , Replaced By: N000125008443
137
HEXAGON NUT. NUT , Replaced By: N913023008002
137
NUT ENGINE MOUNTING M8
137
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
146
NUT ENGINE MOUNTING M8
146
HEXAGON NUT. NUT , Replaced By: N913023008002
164
SCREW. HEXAGON HEAD BOLT SPARE WHEEL M12X30
164
SCREWM 10X20
182
LOCK WASHER FITTING TO BRACKET
182
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
218
LINE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER, NOT USED
218
LINE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
218
LINE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
245
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
245
LINE CONNECTOR TO HEAT EXCHANGER
245
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
245
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
254
HOSE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
263
LINE
272
SEAL RING VALVE TO VALVE,K 025179
290
FITTING COMPRESSED AIR LINE THRU FRAME
290
ELBOW FITTING COMPRESSED AIR LINE THRU FRAME, Replaced By: N000000006195
308
SPACER TUBE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
326
NUT VIBRATION ABSORBER TO CONSOLE
344
SEAL RING FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
344
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
362
THRUST RING THROTTLE VALVE,CONNECTIONS: "1,2"
362
THRUST RING AT CYLINDER CRANKCASE
371
HOSE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
371
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
380
HOSE CLAMP LINE MOUNTING
380
CLAMP , Replaced By: A0059970190
407
BRACKET FUEL LINE TO CROSS MEMBER
407
BRACKET HOSE LINE TO TIMING CASE
416
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
425
SCREW PUMP TO BRACKET
425
SCREW LICENSE PLATE TO BRACKET
434
NUT HEATING PIPE TO BRACKET
443
NUT SPRING-LOADED PUSH ROD
479
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
488
HOSE CLAMP LINE MOUNTING
488
CLAMP , Replaced By: A0059970190
506
BANJO UNION SUCTION LINE
515
SEAL RING DELIVERY LINE
546
FITTING
564
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
573
BANJO UNION CONNECTION OF FUEL LINES
582
BANJO UNION FROM PRESSURE REGULATOR TO ANTI-FREEZE DEVICE,6 900001-6 900006
582
BANJO UNION FEED
582
BANJO UNION , Replaced By: N000000000363
593
CONNECTOR , Replaced By: A0019974972
602
NUT. UNION NUT RETURN
611
HOLLOW SCREW FUEL LINE TO FEED PUMP
620
SEAL RING INJECTION PUMP
999
HOLLOW SCREW
999
SEAL RING
999
SEAL RING
999
CONNECTOR PIPE SOCKET TO THERMOSTAT HOUSING
999
PREHEATER , Replaced By: A3660700079
999
BRACKET FUEL PREHEATING
999
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
999
LINE HEAT EXCHANGER TO CYLINDER HEAD
999
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
999
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING
999
FITTING THERMOSTAT HOUSING BREATHING
999
PREHEATER , Replaced By: A3660700079
999
HOUSING
999
LINE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
999
LINE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
999
LINE FROM HEAT EXCHANGER TO THERMOSTAT HOUSING, FROM ENGINE 253403 YEAR OF MANUFACTURE 1992
999
HOSE FROM CRANKCASE WATER DRAIN TO FUEL HEAT EXCHANGER
999
BANJO UNION
999
BANJO UNION FROM FEED PUMP TO HEAT EXCHANGER
999
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
999
FITTING , Replaced By: A0009907871
999
SEALING RING. SEAL RING ENGINE BREATHING
999
SCREW STOP TO BATTERY CASE
999
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
