Поз.
Артикул
Описание
6
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
8
FITTING , Replaced By: A0029905971
10
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
12
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
12
HOSE , Replaced By: A0009872827
14
FITTING (PARTS KIT),LINE RUPTURE
14
FITTING , Replaced By: A0029906171
16
SLEEVE LINE CONNECTION
18
UNION NUT LINE CONNECTION
18
UNION NUT LINE CONNECTION, Replaced By: N000000006239
20
SEAL CONE LINE CONNECTION
20
GLAND , Replaced By: A0019901967
22
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
22
BANJO UNION , Replaced By: N915052009009
24
BRAKE VALVE (TRAILER CONTROL VALVE), PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
24
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
30
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
30
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 46 05,BOSCH
30
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 52 05, WABCO
30
REPAIR KIT TRAILER CONTROL VALVE TO 001 431 52 05, WABCO
30
REPAIR KIT , Replaced By: A0014306160
36
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
48
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
60
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
72
THRUST RING CHECK VALVE TO AIR RESERVOIR
72
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
84
O-RING CHECK VALVE TO AIR RESERVOIR
96
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
108
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
120
NUT STRAP TO BRACKET
120
NUT , Replaced By: N910113010000
132
BRACKET TRAILER CONTROL VALVE
132
BRACKET TRAILER CONTROL VALVE
144
BRACKET TRAILER CONTROL VALVE
156
SCREW CONSOLE TO SIDE MEMBER
156
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
156
SCREW , Replaced By: N308676012026
168
WASHER LEFT AND RIGHT CONSOLES TO CAB
168
WASHER LEFT AND RIGHT CONSOLES TO CAB
180
SCREW CONSOLE TO SIDE MEMBER
180
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
180
SCREW , Replaced By: N308676012026
192
FITTING ,4 667210
192
FITTING SUPPORT TO CAB
204
WASHER ,4 179002-4 369654
216
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
228
TEST CONNECTION
228
TEST CONNECTION , Replaced By: A0004312931
