Поз.
Артикул
Описание
3
STRUT BUMPER,RIGHT
3
STRUT BUMPER,RIGHT
3
STRUT BUMPER,LEFT
3
STRUT BUMPER,LEFT
3
STRUT BUMPER AT TORSION BAR
3
STRUT BUMPER AT TORSION BAR
6
BRACKET , Replaced By: A3604292940
6
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
6
BRACKET BRAKE LINES
9
BRACKET , Replaced By: A3854290540
9
BRACKET BATTERY CABLE MOUNTING,5 193595
12
CONSOLE , Replaced By: A3878912631
12
CONSOLE PEDESTAL
12
CONSOLE PEDESTAL
15
SCREW , Replaced By: A9429901304
15
SCREW APPARATUS SUPPORT TO FRAME
15
SCREW , Replaced By: N308676014012
15
SCREW SUPPORT TO SIDE MEMBER M 14X45
15
SCREW CONSOLE AND STRUT TO FRAME
15
SCREW BRACKET TO ENGINE MOUNTING
18
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
18
WASHER , Replaced By: N000125015019
21
NUT TORSION BAR TO BEARING BRACKET,5 904661
21
NUT CONSOLE TO SUPPORT
21
NUT , Replaced By: N910113016001
21
NUT CAB ON CONSOLE AT FRAME
21
NUT STEERING SUPPORT TO FRAME
21
NUT , Replaced By: N910113014000
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING LEFT SIDE MEMBER
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING CAB, RIGHT
24
MOUNTING CAB,LEFT
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING , Replaced By: A6558910420
24
MOUNTING CAB,LEFT
24
MOUNTING LEFT SIDE MEMBER
24
MOUNTING CAB, RIGHT
24
MOUNTING CAB, RIGHT
24
MOUNTING CAB,LEFT
24
MOUNTING , Replaced By: A6558910320
24
MOUNTING LEFT SIDE MEMBER
24
MOUNTING LEFT SIDE MEMBER
27
MOUNTING CAB, RIGHT
27
MOUNTING CAB, RIGHT
27
MOUNTING CAB,LEFT
27
MOUNTING CAB,LEFT
30
SPRING , Replaced By: A3878910551, +002A3638910617, +001N071412008200
30
SPRING CAB SUSPENSION,FRONT
30
SPRING CAB SUSPENSION,FRONT
30
SPRING , Replaced By: A3878910551, +002A3638910617, +001N071412008200
33
BUSHING SPRING
33
BUSHING SPRING
36
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
36
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
42
HEADLESS SETSCREW FOR SPRING
42
HEADLESS SETSCREW FOR SPRING
45
WASHER BEARING BRACKET
45
WASHER BEARING BRACKET
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
51
WASHER TORSION BAR TO BEARING BRACKET
51
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
54
NUT COMBINATION CYLINDER TO BEARING BRACKET
54
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
57
LEVER , Replaced By: A3878912556, +002A6208910017
57
LEVER , Replaced By: A3878912556, +002A6208910017
57
LEVER (TILTING LEVER),CAB
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER (TILTING LEVER),CAB
57
LEVER , Replaced By: A3878912756, +002A6208910017
57
LEVER (TILTING LEVER),CAB
60
BUSHING TILTING LEVER
60
BUSHING TILTING LEVER
63
JOINT BEARING , Replaced By: A0019814631
63
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
63
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
63
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
63
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
66
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
66
BUFFER TILTING LEVER
66
BUFFER TILTING LEVER
67
BUSHING TILTING LEVER
69
BUSHING TILTING LEVER
69
BUSHING TILTING LEVER
69
PIN , NO LONGER AVAILABLE, ORDER RANGE OF DELIVERY THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3875860131
72
MOUNTING , Replaced By: A3878905303
72
MOUNTING STABILIZER TO CAB,LEFT,5 094188
72
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
72
MOUNTING SPRING AND STABILIZER,LEFT
72
MOUNTING , Replaced By: A3878905603
72
MOUNTING STABILIZER TO CAB,RIGHT,4 493779
72
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
72
MOUNTING SPRING AND STABILIZER,RIGHT
72
MOUNTING STABILIZER TO CAB,LEFT,5 094188
72
MOUNTING STABILIZER TO CAB,LEFT,5 094188
72
MOUNTING STABILIZER TO CAB,RIGHT,4 493779
72
MOUNTING STABILIZER TO CAB,RIGHT,4 493779
72
MOUNTING STABILIZER TO CAB,LEFT,5 094188
73
PIN
73
PIN
75
BRACKET BUFFER
75
BRACKET BUFFER
78
SCREW , Replaced By: N308676012026
78
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
78
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
78
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
81
SCREW CONSOLE TO SIDE MEMBER
81
SCREW CONSOLE TO SIDE MEMBER
81
SCREW CONSOLE TO SIDE MEMBER
84
NUT SUPPORT TO SIDE MEMBER
84
NUT SUPPORT TO SIDE MEMBER
87
BUFFER , FIRST EXHAUST STOCK OF OLD PARTS,10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207, Replaced By: A3348910072
87
MOUNTING (RUBBER BUFFER)
87
MOUNTING (RUBBER BUFFER)
90
SCREW , Replaced By: N304017008034
90
SCREW , Replaced By: N304017008034
93
WASHER , Replaced By: N009021008213
93
WASHER BRACKET TO LEFT SIDE MEMBER
96
NUT , Replaced By: N913004008001
96
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
99
STABILIZER , Replaced By: A3878900404
99
STABILIZER , Replaced By: A3878900404
99
STABILIZER CAB SUSPENSION,FRONT,5 094188
99
STABILIZER , Replaced By: A6528900104
99
STABILIZER CAB SUSPENSION,FRONT
99
STABILIZER CAB SUSPENSION,FRONT,5 094188
99
STABILIZER CAB SUSPENSION,FRONT,5 094188
102
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
102
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
105
SCREW PLUG STABILIZER
105
SCREW PLUG STABILIZER
105
MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
SCREW PLUG STABILIZER
105
MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
108
JOINT BEARING
108
JOINT BEARING
108
JOINT BEARING
108
JOINT BEARING
108
JOINT BEARING , Replaced By: A0019814631
108
JOINT BEARING , Replaced By: A0009817231
108
JOINT BEARING , Replaced By: A0009817331
108
JOINT BEARING , Replaced By: A0009817231
109
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
110
SCREW PLUG STABILIZER
111
CONSOLE CAB SUSPENSION,FRONT RIGHT
111
CONSOLE CAB SUSPENSION,FRONT LEFT
111
CONSOLE CAB SUSPENSION,FRONT RIGHT
111
CONSOLE , Replaced By: A6208910731
111
CONSOLE CAB SUSPENSION,FRONT LEFT
111
CONSOLE , Replaced By: A6208910631
123
SCREW , Replaced By: N308676012015
123
SCREW LEFT AND RIGHT CONSOLES TO CAB
123
SCREW LEFT AND RIGHT CONSOLES TO CAB
123
SCREW LEFT AND RIGHT CONSOLES TO CAB
123
SCREW , Replaced By: N308676012031
123
SCREW , Replaced By: N308676012011
123
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
123
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
126
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
126
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
126
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
126
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
126
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
126
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
129
SCREW , Replaced By: N308676014020
129
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
129
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
129
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
132
SCREW BRACKET TO CAB CONSOLE,K 035197
132
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
132
SCREW BRACKET TO CAB CONSOLE,K 035197
135
LOCK WASHER FITTING TO BRACKET
135
LOCK WASHER FITTING TO BRACKET
138
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
138
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
141
WASHER LEFT AND RIGHT CONSOLES TO CAB
141
WASHER LEFT AND RIGHT CONSOLES TO CAB
141
WASHER LEFT AND RIGHT CONSOLES TO CAB
145
SCREW STABILIZER TO BEARING
147
NUT , Replaced By: N910113014001
147
NUT BRACKET TO SIDE MEMBER
147
NUT BRACKET TO SIDE MEMBER
150
WASHER BRACKET TO SIDE MEMBER,5 703114
153
NUT , Replaced By: N910113014001
153
NUT BRACKET TO SIDE MEMBER
153
NUT BRACKET TO SIDE MEMBER
156
WASHER , Replaced By: N000125015019
156
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
158
SCREW , Replaced By: N000961014064
158
SCREW BRACKET TO SIDE MEMBER
158
SCREW BRACKET TO SIDE MEMBER
159
NUT , Replaced By: N910113014001
