Поз.
Артикул
Описание
639
TANK , Replaced By: A0004664502
640
TANK OIL
641
PIPETO 000 466 38 02
642
OIL DIPSTICK
642
OIL DIPSTICK , Replaced By: A0004660867
644
COVERTO 000 466 38 02
645
FILLER CAP
647
SEAL RINGTO 000 466 38 02
648
SEAL RING
650
FILTER CARRIERTO 000 466 38 02
651
BRACKET
652
FILTER
655
SEAL RINGTO 000 466 38 02
658
CONNECTORTO 000 466 38 02
663
NUTTO 000 466 38 02
666
CENTERING RINGTO 000 466 38 02
668
SPACER WASHERTO 000 466 38 02
668
WASHER , Replaced By: A9402680552
670
SPACER TUBETO 000 466 38 02
673
COVER PLATETO 000 466 38 02
676
RUBBER SLEEVETO 000 466 38 02
679
BRACKET OIL TANK
681
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
683
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
683
SCREW , Replaced By: N304017010028
685
SCREW OIL TANK TO BRACKET
685
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
685
SCREW , Replaced By: N000000001149
685
SCREW , Replaced By: A0029903712
686
NUT OIL TANK TO BRACKET
686
NUT , Replaced By: N913002006009
686
NUT PUMP TO BRACKET
686
NUT , Replaced By: N913004006001
687
LINE FROM POWER STEERING PUMP TO HOSE
690
SEAL CONE LINE CONNECTION
690
GLAND , Replaced By: A0019901967
692
UNION NUT LINE CONNECTION, Replaced By: N000000006239
695
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
695
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
695
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
696
LINE , NOT USED
696
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
697
FITTING DELIVERY LINE TO PUMP
699
LINE FROM STEERING TO OIL TANK
701
UNION NUT LINE CONNECTION
703
GLAND LINE CONNECTION
706
HOSE , NOT USED
706
HOSE , Replaced By: A3859971682
706
HOSE , Replaced By: A6999974082
706
HOSE , Replaced By: A3439970582
709
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
709
CLAMP , Replaced By: N000000000667
711
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
714
LINE , Replaced By: A0004291601
714
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
717
UNION NUT LINE CONNECTION, Replaced By: N000000006243
720
SEAL CONE LINE CONNECTION
720
GLAND , Replaced By: A0019901267
723
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
723
HOSE , Replaced By: A3859971582
726
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
726
CLAMP , Replaced By: N000000000667
729
LINE FROM OIL TANK TO HOSE, NOT USED
730
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
730
HOSE , Replaced By: A3859971582
731
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
731
CLAMP , Replaced By: N000000000667
732
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
732
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
732
BRACKET , Replaced By: A3812950440
734
BRACKET DELIVERY AND SUCTION LINES TO FRAME
734
BRACKET , Replaced By: A6564660040
737
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
737
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
740
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
744
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
744
BRACKET , Replaced By: A3524290740
744
BRACKET , Replaced By: A3875015820
746
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
748
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
750
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
752
NUT PUMP TO BRACKET
752
NUT , Replaced By: N913004006001
999
BOOT FIXED PART OF JOINT
999
CLAMP CLAMP, TWO-HOLE
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
DRAG LINK END , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602648
999
DRAG LINK END , Replaced By: A0004602848
999
DRAG LINK END , Replaced By: A0004602948
999
DRAG LINK END , Replaced By: A0004603548
999
DRAG LINK END , Replaced By: A0014600848
999
DRAG LINK END , Replaced By: A0014601248, +001A0019905451
999
DRAG LINK END , Replaced By: A0014601448, +001A0019905451
999
BOOT DRAG LINK
999
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
999
FILTER , Replaced By: A0004660604
999
SEALING CORD , Replaced By: A0059970848
999
ELBOW FITTING SUCTION LINE TO OIL PUMP
999
DRAG LINK END , Replaced By: A0014602248
999
DRAG LINK END , Replaced By: A0014602248
999
DRAG LINK END , Replaced By: A0014602348
999
DRAG LINK END , Replaced By: A0014607748
999
DRAG LINK END , Replaced By: A0014607848
999
SEAL RING , Replaced By: A0059970848
999
NEEDLE BEARING INSIDE AND OUTSIDE
999
HOSE , Replaced By: A0009978152
999
HOSE , Replaced By: A0009978152
999
PROTECTIVE CAP
999
STEERING WHEEL ,4 430199, Replaced By: A3834640201, +001A0004640432
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004621796
999
SPACER TUBE STEERING INTERMEDIATE ARM BEARING TO 622 461 00 40
999
WASHER PITMAN ARM
999
STEERING COLUMN BRACKET
999
RING STEERING SHAFT
999
WASHER , Replaced By: A3814620475
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 456943, Replaced By: A3814621196
999
LINE FROM RETURN LINE TO OIL TANK, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
999
LINE RETURN, FROM STEERING TO OIL TANK,5 593344
999
BRACKET OIL TANK
999
DRAG LINK , Replaced By: A3874604405
999
LINE FROM PUMP TO HIGH PRESSURE HOSE, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
999
DRAG LINKLEMFOERDER, FROM IDENT NO. 4 118555 EXCEPT FOR4 127151-4 1298974 298136
999
DRAG LINKEHRENREICH, FROM IDENT NO. 4 118555 EXCEPT FOR4 127151-4 1298974 298136
999
STEERING SUPPORT
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
COVER PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
999
BRACKET DELIVERY AND SUCTION LINES TO FRAME
999
STEERING BRACKET ,4 298136
999
STEERING BRACKET ,4 298136
999
STEERING BRACKET ,4 298137
999
DRAG LINK , Replaced By: A3914602305
999
STEERING BRACKET ,4 298137
999
DRAG LINK FROM INTERMEDIATE LEVER III TO FRONT AXLE II LEMFOERDER
999
DRAG LINK FROM INTERMEDIATE LEVER III TO FRONT AXLE II EHRENREICH
999
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III LEMFOERDER, FROM 08.95 COMPONENT PARTS NOT AVAILABLE
999
DRAG LINK FROM STEERING SUPPORT II TO STEERING SUPPORT III EHRENREICH, COMPONENT PARTS NOT AVAILABLE
999
PITMAN ARM ,4 298137-4 436182, Replaced By: A3914630601, +001A3914601905
999
STEERING INTERMEDIATE ARM ,4 298136
999
STEERING INTERMEDIATE ARM ,4 298136
999
PITMAN ARM FRONT
999
STEERING INTERMEDIATE ARM ,4 298137
999
WASHER PITMAN ARM
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
999
NUT DRAG LINK TO LEVER
999
SCREW CLAMP, TWO-HOLE
999
SCREW , Replaced By: N308676012017
999
SCREW STEERING SUPPORT TO FRAME M 14X55
999
SCREW STEERING SUPPORT TO FRAME M 14X50
999
SCREW , Replaced By: N308676012026
999
SCREW BRACKET TO FRAME M 12X35
999
SCREW , Replaced By: N308676014008
999
SCREW , Replaced By: N308676014012
999
SHEET METAL SCREW , Replaced By: N007981005321
999
SHEET METAL SCREW BOOT TO CAB FLOOR
999
SHEET METAL SCREW PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
999
GREASE NIPPLE , Replaced By: N071412008102
999
GREASE NIPPLE
999
NUT STEERING WHEEL TO STEERING COLUMN
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
HEXAGON HEAD BOLT. SCREW CLAMP TO DRAG LINK
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
999
SCREW MOUNTING TO CONSOLE M 14X35
999
SCREW SUPPORT TO SIDE MEMBER M 14X45
999
NUT SUPPORT TO SIDE MEMBER
999
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
999
NUT STEERING SUPPORT TO FRAME
999
NUT SHOCK ABSORBER TO FRONT SPRING, Replaced By: N910113022000
999
NUT , Replaced By: N910113012003
999
NUT , Replaced By: N910113014000
999
NUT , Replaced By: N910113022001
