Поз.
Артикул
Описание
636
CONSOLE CONSOLE TO FRAME,4 330046
637
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
637
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
639
NUT BRACKET TO SIDE MEMBER
639
NUT BRACKET TO SIDE MEMBER
639
NUT , Replaced By: N910113014001
642
STRUT CAB MOUNTING,REAR (LEAF SPRING SUSPENSION)
642
STRUT CAB MOUNTING,REAR (LEAF SPRING SUSPENSION)
642
STRUT , Replaced By: A6558910224, +002A6558910118
645
SHIM STRUT TO CONSOLE
645
SHIM STRUT TO CONSOLE
648
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
648
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
648
SCREW , Replaced By: N308676012012
651
LOCK WASHER
651
LOCK WASHER
654
SPRING (LEAF SPRING),CAB SUSPENSION
654
SPRING (LEAF SPRING),CAB SUSPENSION
654
SPRING , Replaced By: A3878911051
657
BUSHING LEAF SPRING
657
BUSHING LEAF SPRING
660
TUBE LEAF SPRING, TO BE ADAPTED DURING ASSEMBLY
660
TUBE LEAF SPRING, TO BE ADAPTED DURING ASSEMBLY
664
WASHER LEAF SPRING TO STRUT, DISCONTINUED,PART IS NO LONGER REQUIRED
664
WASHER LEAF SPRING TO STRUT, DISCONTINUED,PART IS NO LONGER REQUIRED
667
SCREW SPRING TO STRUT, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 215244
667
SCREW SPRING TO STRUT, MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB5 215244
670
WASHER LEAF SPRING TO STRUT
670
WASHER LEAF SPRING TO STRUT
673
NUT SUPPORT TO SIDE MEMBER
673
NUT SUPPORT TO SIDE MEMBER
676
RAIL (CONNECTING RAIL),4 330046
679
CYLINDRICAL PIN CONNECTING RAIL,4 330046
682
BUFFER RAIL STOP
682
BUFFER RAIL STOP
682
BUFFER , Replaced By: A3878910323
685
MOUNTING CAB SUSPENSION,REAR
685
MOUNTING CAB SUSPENSION,REAR
688
SCREW BUFFER AND MOUNTING TO RAIL M 8X20
688
SCREW BUFFER AND MOUNTING TO RAIL M 8X20
691
SCREW PIPE CLAMP
691
SCREW , Replaced By: N304017008021
694
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
694
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
697
WASHER BRACKET TO CROSS MEMBER
697
WASHER BRACKET TO CROSS MEMBER
699
WASHER EXHAUST MUFFLER TO STRAP
699
WASHER EXHAUST MUFFLER TO STRAP
699
WASHER , Replaced By: N000125008443
700
SHIM ,4 330046
702
MOUNTING CAB MOUNTING,REAR,4 972621
705
PIN BEARING BRACKET,4 972621
708
LOCK RING BEARING BRACKET,4 972621
708
LOCK RING BEARING BRACKET,4 972621
711
PLATE MOUNTING AND RAIL TO LEAF SPRING
711
PLATE MOUNTING AND RAIL TO LEAF SPRING
713
SCREW MOUNTING AND RAIL TO LEAF SPRING
713
SCREW MOUNTING AND RAIL TO LEAF SPRING
716
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
716
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
719
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
719
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
719
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
719
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
722
RUBBER MOUNTING
722
RUBBER MOUNTING ,4 330046
722
RUBBER MOUNTING , Replaced By: A0008910001
725
BUSHING
725
BUSHING ,4 330046
725
BUSHING , Replaced By: A0008910117
728
WASHER VIBRATION ABSORBER,4 330046
731
SCREW SHOCK ABSORBER TO CONSOLE M 14X130,4 330046
734
NUT BRACKET TO SIDE MEMBER
734
NUT , Replaced By: N910113014001
737
SCREW AT CROSS MEMBER
740
NUT BRACKET TO SIDE MEMBER
740
NUT , Replaced By: N910113014001
743
FASTENER (CENTRAL LOCK) CAB LOCKING MECHANISM
743
FASTENER (CENTRAL LOCK) CAB LOCKING MECHANISM
743
FASTENER , Replaced By: A0008902389
743
FASTENER , Replaced By: A0008902389
743
FASTENER , Replaced By: A0008902389
746
ROD CENTRAL LOCK
746
ROD CENTRAL LOCK,5 002668
746
ROD CENTRAL LOCK
749
PIN PULL TO FASTENER, 385.019 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB,385.068,069 ONLY VEHICLES HAVING NO MECEDES-BENZ CAB
752
WASHER BRACKET TO CROSS MEMBER
752
WASHER BRACKET TO CROSS MEMBER
754
CONSOLE CENTRAL LOCK
755
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
755
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
758
SCREW END PIECE TO EXHAUST PIPE M 10X25
758
SCREW END PIECE TO EXHAUST PIPE M 10X25
761
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
761
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
763
NUT STRAP TO BRACKET
763
NUT STRAP TO BRACKET
763
NUT , Replaced By: N910113010000
766
BRACKET ROD THRU CAB
766
BRACKET ROD THRU CAB
769
SEAL ROD THRU CAB
769
SEAL ROD THRU CAB
772
CLAMPING SLEEVE ROD TO BRACKET
772
CLAMPING SLEEVE ROD TO BRACKET
775
LEVER CAB LOCKING MECHANISM,5 132082
778
BUSHING LEVER TO CAB
778
BUSHING LEVER TO CAB
781
HANDLE CAB LOCKING MECHANISM
781
HANDLE CAB LOCKING MECHANISM
781
HANDLE , USED WITH MEDIUM-LENGTH AND LONG MERCEDES-BENZ CABS, Replaced By: A6208910073
784
SCREW BUSHING AND LEVER TO CAB
787
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
787
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
787
NUT , Replaced By: N913004008001
790
CLAMPING SLEEVE LEVER MOUNTING
790
CLAMPING SLEEVE LEVER MOUNTING
790
CLAMPING SLEEVE , Replaced By: N001481005039
793
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
793
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
793
WASHER , Replaced By: N000125015019
796
RETAINING RING CAB LOCKING MECHANISM
796
RETAINING RING CAB LOCKING MECHANISM
799
PIN ROD TO LEVER
802
WASHER BRACKET TO CROSS MEMBER
802
WASHER BRACKET TO CROSS MEMBER
999
RUBBER MOUNTINGTO 620 890 02 19
999
JOINT BEARING , Replaced By: A0019814631
999
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
JOINT BEARING
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
SCREW , Replaced By: N308676012013
999
SCREW , Replaced By: A3959900501
999
SCREW , Replaced By: A0029908201
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
SCREW , Replaced By: A3169900014
999
SCREWM 14X14X22X40
999
SCREWM 14X14X18X32
999
SCREWM 14X14X27X45
999
SCREWM 16X18X18X40
999
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
999
SCREWM 12X13X18X35
999
SCREWM 12X14X13X35
999
SCREWM 14X14X24X42
999
SCREWM 14X15X15X32
999
SCREWM 14X15X21X38
999
SCREW PLATE TO SIDE MEMBER
999
SCREWM 16X17X22X42
999
SCREWM 12X13X21X38
999
SCREWM 14X15X27X44
999
SCREWM 14X15X17X34
999
SCREWM 14X15X29X46
999
SCREWM 14X15X19X36
999
SCREWM 12X13X15X32
999
SCREW , Replaced By: A0009906314
999
SCREWM 14X14X32X50
999
FLANGE HOLLOW RUBBER SPRING
999
BUSHING HOLLOW RUBBER SPRING
999
MOUNTING , Replaced By: A3878918120
999
LOCKING MECHANISM CAB LOCKING MECHANISM,RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
999
BRACKET CAB, RIGHT, FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 146509
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
BRACKET , Replaced By: A3813177840
999
BRACKET , Replaced By: A3813177940
999
SUPPORT EXPANSION TANK,4 369034
999
REINFORCEMENT EXPANSION TANK TO BRACKET,4 369034
999
GUMMED LABEL CAB LOCKING MECHANISM
999
SCREWM 12X13X35X52
999
SCREWM 14X15X35X52
999
SCREWM 14X15X31X48
999
SCREWM 10X11X26.5X46
999
SCREWM 12X12X10X25
999
SCREW , Replaced By: A3229903101
999
SCREW , Replaced By: N308676016020
999
SCREWM 16X16X22X40
999
SCREW , Replaced By: N000961016118
999
SCREWM 12X12X11X26
999
SCREWM 12X12X13X28
999
SCREWM 16X16X20X38
999
SCREWM 16X16X30X48
999
SCREWM 16X16X32X50
999
SCREWM 14X14X18X34
999
SCREWM 12X12X15X30
999
SCREWM 12X12X17X32
999
SCREWM 18X18X23X45
999
SCREW , Replaced By: N000961018043
999
STRUT BUMPER,RIGHT
999
REINFORCEMENT LEFT,FOR TORSION BAR,5 184731
999
REINFORCEMENT RIGHT,FOR TORSION BAR,5 184731
999
CROSS MEMBERNO.3A
999
CROSS MEMBER , Replaced By: A3933100246
999
GUSSET PLATE FRONT LEFT, TO BE ADAPTED DURING ASSEMBLY
999
GUSSET PLATE , Replaced By: A6203120987
999
COUPLING PIN FOR COUPLING MOUTH
999
STRUT BUMPER AT TORSION BAR
999
GUIDE LEFT
999
PIN , NO LONGER AVAILABLE, ORDER RANGE OF DELIVERY THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3875860131
999
GUIDE RIGHT
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
