Поз.
Артикул
Описание
10
TANK , Replaced By: A0004664502
12
TANK OIL
15
PIPETO 000 466 38 02
17
OIL DIPSTICK , Replaced By: A0004660867
17
OIL DIPSTICK
20
COVERTO 000 466 38 02
22
FILLER CAP
24
SEAL RINGTO 000 466 38 02
26
SEAL RING
28
FILTER CARRIERTO 000 466 38 02
30
BRACKET
32
FILTER , Replaced By: A0004660604
32
FILTER
36
SEALING CORD , Replaced By: A0059970848
36
SEAL RING , Replaced By: A0059970848
36
SEAL RINGTO 000 466 38 02
40
CONNECTORTO 000 466 38 02
44
NUT
48
CENTERING RINGTO 000 466 38 02
52
WASHER , Replaced By: A9402680552
52
SPACER WASHERTO 000 466 38 02
56
SPACER TUBETO 000 466 38 02
60
COVER PLATETO 000 466 38 02
64
RUBBER SLEEVETO 000 466 38 02
68
BRACKET OIL TANK
72
SCREW , Replaced By: N304017010028
72
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
76
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
78
SCREW , Replaced By: A0029903712
78
SCREW , Replaced By: N000000001149
78
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
78
SCREW OIL TANK TO BRACKET
81
NUT , Replaced By: N913004006001
81
NUT PUMP TO BRACKET
81
NUT , Replaced By: N913002006009
81
NUT OIL TANK TO BRACKET
84
LINE FROM POWER STEERING PUMP TO HOSE
84
LINE FROM PUMP TO HIGH PRESSURE HOSE, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
85
GLAND , Replaced By: A0019901967
85
SEAL CONE LINE CONNECTION
86
UNION NUT LINE CONNECTION, Replaced By: N000000006239
87
HOSE , Replaced By: A0009978152
87
HOSE , Replaced By: A0009978152
87
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
87
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
87
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
88
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
88
LINE , NOT USED
90
SCREW-IN FITTING DELIVERY LINE TO PUMP
93
GLAND , Replaced By: A0019901967
93
SEAL CONE LINE CONNECTION
96
UNION NUT LINE CONNECTION, Replaced By: N000000006239
99
LINE FROM STEERING TO OIL TANK
100
GLAND LINE CONNECTION
101
UNION NUT LINE CONNECTION
102
HOSE , Replaced By: A3439970582
102
HOSE , Replaced By: A6999974082
102
HOSE , Replaced By: A3859971682
102
HOSE , NOT USED
105
CLAMP HOSE TO FITTING AND TO OIL TANK
105
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
108
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
113
GLAND , Replaced By: A0019901267
113
SEAL CONE LINE CONNECTION
114
UNION NUT LINE CONNECTION, Replaced By: N000000006243
116
HOSE , Replaced By: A3609970982
116
HOSE , Replaced By: A3859971582
116
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
118
CLAMP , Replaced By: N000000000667
118
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
120
LINE FROM OIL TANK TO HOSE, NOT USED
126
HOSE , Replaced By: A3859971582
126
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
128
CLAMP , Replaced By: N000000000667
128
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
132
ELBOW FITTING SUCTION LINE TO OIL PUMP
136
BRACKET , Replaced By: A3812950440
136
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
136
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
140
BRACKET , Replaced By: A6564660040
140
BRACKET DELIVERY AND SUCTION LINES TO FRAME
144
SCREW , Replaced By: N308676012026
144
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
148
NUT SUPPORT TO SIDE MEMBER
152
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
152
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
154
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
155
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
157
BRACKET , Replaced By: A3875015820
157
BRACKET , Replaced By: A3524290740
157
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
158
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
LOCK WASHER STEP SWITCH
999
NUT STEERING WHEEL TO STEERING COLUMN
999
CLAMPING SLEEVE STEERING WHEEL TILT ADJUSTMENT,4 231946-4 430729
999
SCREW WASHER TO STEERING COLUMN BRACKET, ONLY ON VEHICLES WITH MERCEDES-BENZ PLATFORN4 492544
999
SCREW GUIDE TO STEERING COLUMN END,4 430730
999
SCREW TORSION BAR TO SHACKLE,5 903514
999
SCREW ,5 903514, Replaced By: N000960012353
999
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER TYP 260 G140
999
SCREW
999
THRUST PLATE , Replaced By: A3834620363
999
HANDLE RIGHT,4 430730
999
SPRINGTO 387 460 14 09,10/20 4 134653
999
BRACKET DELIVERY AND SUCTION LINES TO FRAME
999
COVER PROTECTIVE SLEEVE TO CAB FLOOR,4 188586
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
PROTECTIVE SLEEVE UNIVERSAL JOINT COVERING,4 188586
999
STEERING SUPPORT
999
BRACKET OIL TANK
999
LINE RETURN, FROM STEERING TO OIL TANK,5 593344
999
LINE FROM RETURN LINE TO OIL TANK, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
999
WASHER ADJUSTABLE STEERING COLUMN
999
THRUST PLATE
999
HANDLE , Replaced By: A6554600469
999
HANDLE , Replaced By: A3834601969
999
HANDLE LEFT,4 4307304 727153
999
STEERING COLUMN END , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 727154 - 5 468371, Replaced By: A3054600452
999
HANDLE RIGHT,4 231946-4 430729
999
BEARING STEERING SHAFT,4 430730
999
BEARING STEERING SHAFT,4 430730
999
BEARING , EXHAUST STOCK OF OLD PARTS UP TO IDENT-NO. 5 210006, Replaced By: A3834601437
999
STEERING COLUMN END ,4 4307304 727153, Replaced By: A3834601652, +001A6754600369, +001A3834620763
999
BEARING , Replaced By: A3054600337
999
STEERING COLUMN BRACKET ADJUSTABLE STEERING COLUMN,4 430730
999
STEERING COLUMN BRACKET , Replaced By: A3834600931
999
STEERING COLUMN END ADJUSTABLE STEERING COLUMN,4 231946-4 430729
999
BEARING STEERING SHAFT,4 430729
999
STEERING COLUMN BRACKET ADJUSTABLE STEERING COLUMN,4 231946-4 430729
999
GUIDE STEERING SHAFT,4 430730
999
GUIDE , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 430730 - 5 468371, Replaced By: A3834600136
999
RING STEERING SHAFT
999
STEERING COLUMN BRACKET
999
COVER
999
STEERING COLUMN END ADJUSTABLE STEERING COLUMN,4 727154
999
BEARING , EXHAUST STOCK OF OLD PARTS UP TO IDENT-NO. 5 210006, Replaced By: A3834601337
999
STEERING WHEEL ,4 430199, Replaced By: A3834640201, +001A0004640432
999
PROTECTIVE CAP
999
SLEEVE STEERING COLUMN BEARING, NOT FOR USE WITH MERCEDES-BENZ CAB4 375508
999
NEEDLE BEARING
999
DISC SPRING STEERING WHEEL TILT ADJUSTMENT,4 231946-4 430729
999
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
