Поз.
Артикул
Описание
8
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
16
LEVER CONTROL
16
LEVER , Replaced By: A4270700721, +001N000988012009, +001N006799009002
24
BUSHING
32
BALL PIVOT LEVER
32
BALL PIVOT , Replaced By: A3129910120
40
BRACKET
48
GREASE NIPPLE , Replaced By: A0009970488
48
GREASE NIPPLE
56
FITTED WASHER CLUTCH SLAVE CYLINDER TO RELEASE YOKE,4 667416
64
LOCK PLATE
72
SCREW , Replaced By: N304017010002
80
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
80
PULL ROD , Replaced By: N900331006629
88
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
96
NUT BALL PIVOT TO LEVER
104
NUT L.H. THREAD
112
BALL SOCKET ACCELERATOR CONTROL
120
BALL SOCKET PULL ROD TO LEVER
128
BEARING TUBE INJECTION PUMP CONTROL
136
BEARING TUBE INJECTION PUMP CONTROL
158
SCREW STEERING SUPPORT TO FRAME M 10X75
166
SPACER TUBE BEARING TUBE ASSEMBLY TO TIMING CASE AND TO CYLINDER CRANKCASE
999
LEVER CONTROL
