Поз.
Артикул
Описание
5
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
5
SPRING WASHER ALTERNATOR CONNECTION W
5
SPRING WASHER ALTERNATOR CONNECTION D+
5
SPRING WASHER , Replaced By: N000137008212
5
SPRING WASHER HEATER PLUG CABLE HARNESS
8
NUT , Replaced By: N304032005005
8
NUT , Replaced By: N304032008006
8
NUT BALL PIVOT TO LEVER
8
NUT IN CASE OF SUBSEQUENT INSTALLATION
8
NUT
11
FAN
14
PULLEY ONE-GROOVE
17
SUPPORT ALTERNATOR
23
BUSHING
24
BRACKET PIPE BEND TO CYLINDER CRANKCASE
29
SCREW BRACKET WITH FUEL FILTER TO ENGINE
29
SCREWM 10X20
32
SPRING WASHER BRACKET TO TIMING CASE
38
SCREW REAR SPRING BRACKET TO FRAME M 14X35
50
SCREW DUMPER SHAFT,5 515436
50
SCREW , Replaced By: N304014010015
56
WASHER SUPPORT TO ALTERNATOR TO 352 150 09 73
59
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
62
CLAMPING BOLT (CLAMPING BOLT)
65
BUSHING
68
CLAMPING PIECE TIGHTENER PULLEY
68
CLAMPING PIECE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3141550228
71
NUT TIGHTENER PULLEY TO LEVER
74
SCREW BEARING BRACKET TO CONSOLE
75
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
75
WASHER , Replaced By: N000433013010
75
WASHER COVER TO P.T.O. CASE
80
NUT BRACKET TO SIDE MEMBER
80
NUT BRACKET TO FRAME
83
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
86
WASHER SUPPORT TO ALTERNATOR TO 352 150 09 73
92
GROUND CABLE GENERATOR TO ENGINE SUPPORT
93
WASHER , Replaced By: N000433005304
93
WASHER BOOT TO CAB FLOOR
94
NUT TWO-WAY VALVE TO BRACKET
999
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
999
SPRING WASHER CAB FLOOR
