Поз.
Артикул
Описание
29
COVER OIL FILTER
29
COVER OIL FILTER,OIL COOLER,017497
29
COVER OIL FILTER, 401-403 129660 404 001964 407 017497
63
THREADED INSERT
63
THREADED UNION OIL FILTER
63
THREADED INSERT
63
THREADED INSERT
63
THREADED INSERT DE-AERATION LINE TO COOLING WATER LINE
69
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
85
WASHER OIL COOLER COVER
108
OIL COOLER , Replaced By: A0011881101
108
OIL COOLER ,907 845891
108
OIL COOLER
108
OIL COOLER ,121800907 845891
108
OIL COOLER , ORDER NUMBER: 001 188 89 01/33
108
OIL COOLER , ORDER NUMBER: 001 188 88 01/33
108
OIL COOLER , Replaced By: A0011881201
122
SEAL. GASKET , Replaced By: A3661880880
124
GASKET OIL COOLER COVER, 401-403 129660 404 001964 407 017497
124
GASKET , Replaced By: A4421840580
136
SCREW STOP TO BATTERY CASE
142
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
142
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
154
SCREW VALVE TO BRACKET M 8X55
154
SCREW , Replaced By: N304017008043
156
SPRING WASHER , Replaced By: N000137008212
156
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
158
SCREW , Replaced By: N304017008016
158
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
160
SCREW , Replaced By: N304017008043
160
SCREW , Replaced By: N304017008053
160
SCREW VALVE TO BRACKET M 8X55
160
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
160
SCREW STRAP TO BRACKET
174
SEAL RING
176
SPRING WASHER , 401-403 075551 404 000678
178
SPRING BY-PASS VALVE
180
NUT ROD TO TORSION BAR
182
VALVE
184
SCREW PLUG
194
FILTER ELEMENT WITH GASKETS
194
FILTER ELEMENT RANGE OF DELIVERY
194
FILTER ELEMENT , Replaced By: A4011800009
195
SEAL RING FILTER BOWL TO FILTER HEAD
196
FILTER BOWL OIL FILTER BOWL
196
FILTER BOWL , UP TO ENGINE 923826 YEAR OF MANUFACTURE 1988
196
OIL TANK , Replaced By: A4031800011
196
OIL TANK , Replaced By: A4011800011
196
HOUSING , Replaced By: A4011800011
202
SCREW PLUG , Replaced By: A4429970030
202
SCREW PLUG SHIFTING SHAFT DETENT
206
SEAL RING VALVE TO VALVE,K 025179
222
SCREW OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
222
SCREW OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
222
SCREW
222
SCREW OIL FILTER HOUSING TO OIL FILTER HEAD, UP TO ENGINE 923826 YEAR OF MANUFACTURE 1988
226
SEAL RING FUEL LINE TO FEED PUMP
226
SEAL RING FROM FUEL TANK TO FUEL TANK
232
VALVE
234
SPRING BY-PASS VALVE
236
SEAL RING
238
SCREW PLUG
240
SEAL RING TO PLUG AIR COMPRESSOR CYLINDER HEAD TO 003 131 48 01
240
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
240
SEAL RING
242
SCREW PLUG
242
SCREW PLUG , UP TO ENGINE 921 001982 927 000355 928 000589 929 000007
242
SCREW PLUG , Replaced By: A4039970230
244
SCREW PLUG
252
SEAL RING FROM FUEL TANK TO FUEL TANK
252
SEAL RING FUEL LINE TO FEED PUMP
254
SCREW PLUG, FILLING OIL DRAIN
254
SEAL RING FROM FUEL TANK TO FUEL TANK
254
SCREW PLUG FUEL TANK
254
SCREW PLUG , Replaced By: N007604014110
254
SCREW PLUG , Replaced By: A1119970330
256
SEAL RING OIL LINE TO OIL COOLER
258
SCREW PLUG
258
SCREW PLUG OIL COOLER,5 360280
258
SCREW PLUG , Replaced By: A0009973532
258
SCREW PLUG , Replaced By: N000908026008
260
SEAL RING
260
SEAL RING SPEEDOMETER DRIVE
260
SEAL RING OIL DRAIN 30X36 MM
264
SCREW PLUG FUEL TANK
264
SEAL RING FUEL LINE TO FEED PUMP
264
SCREW PLUG , Replaced By: N007604014110
264
SEALING RING. SEAL RING ENGINE BREATHING
264
SEAL RING INJECTION PUMP
282
GASKET , Replaced By: A4421840580
282
GASKET OIL COOLER COVER, 401-403 129660 404 001964 407 017497
286
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
314
SPRING WASHER STEERING COLUMN BRACKET TO CAB
320
SCREW OIL FILTER TO CYLINDER CRANKCASE
320
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
320
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
320
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
320
SCREW BRACKET TO SIDE MEMBER M10X35
320
SCREW , Replaced By: N304017010047
999
GASKET , Replaced By: N917003026003
999
FITTING WATER SEPARATOR
999
UNION NUT
999
SCREW FITTING , Replaced By: A4039971172
999
LOCKING CONE
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
SCREW EXHAUST PIPE,FRONT,ON FLYWHEEL HOUSING
999
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
999
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
999
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
999
SCREW CLAMP ON BRACKET
999
ROUND SECTION SEAL RING INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
ROUND SECTION SEAL RING INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
PART NAME MISSING OIL FEED LINE TO OIL FILTER, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
CLAMPING PIECE OIL FEED LINE TO OIL FILTER, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
CLAMPING PIECE OIL FEED LINE TO OIL FILTER, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
PIPE ELBOW OIL RETURN LINE TO OIL PAN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
PIPE ELBOW OIL LINES ON LONG-LIFE OIL FILTER
999
SCREW CONNECTOR TO REAR SHIFTING ROD
999
SCREW CLUTCH OPERATION,4 282707
999
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
999
SCREW SUPPORT TO FENDER
999
SCREW LINE MOUNTING M 10X50
999
SEAL RING POWER STEERING PUMP TO BEARING FLANGE
999
SEAL RING FILTER BOWL TO FILTER HEAD
999
SEAL RING
999
SEAL RING BRAKE POWER REGULATOR,CONNECTION: "41,42",067640
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010047
999
SCREW , Replaced By: N304017008018
999
SCREW , Replaced By: N304014010004
999
SCREW , Replaced By: N304017008018
999
CAP BOLT. SCREW BUMPER TO BRACKET,5 398606
999
SCREW INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
SCREW PLUG OIL FILLING
999
SCREW PLUG FRONT COVER
999
SCREW PLUG TO PLUG THE OIL PASSAGES
999
LOCK RING SHIFT LEVER BEARING
999
WASHER VIBRATION ABSORBER TO BRACKET
999
SPRING WASHER , Replaced By: N000137008212
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW PLUG , Replaced By: A1119970330
999
BRACKET OIL FEED LINE TO OIL FILTER
999
SCREW PLUG OIL LINES ON LONG-LIFE OIL FILTER
999
OIL LINE OIL LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
OIL LINE OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
OIL LINE OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
FITTING OIL FEED LINE TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SPACER
999
OIL FILTER COVER
999
BRACKET OIL FEED LINE TO OIL FILTER
999
GASKET , Replaced By: A4421880580
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
HOUSING , Replaced By: A4241800037
999
COVER
999
BRACKET OIL LINES
999
BRACKET OIL LINES
999
CLAMPING BRACKET OIL FILTER TO BRACKET,5 218089
999
COVER , Replaced By: A4441801538
999
COVER
999
COVER , Replaced By: A4071800438
999
LINE
999
BAFFLE PLATE OIL COOLER HOUSING,001965
999
GASKET , Replaced By: A4441880080
999
GASKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403, 421-423, 441-443 735001 404, 424, 444 051301 407, 447015077, Replaced By: A4441840080
999
COVER OIL COOLER HOUSING
999
COVER OIL FILTER
999
HOUSING , Replaced By: A4041800637
999
PARTITION PANEL ,001964
999
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
999
SCREW PLUG
999
GASKET , Replaced By: N917003026000
999
GASKET , Replaced By: A4421880280
999
GASKET , Replaced By: A4031840380
999
VALVE , Replaced By: A4031840132
999
FILTER ELEMENT , Replaced By: A4021800009
999
COVER OIL FILTER,OIL COOLER
999
COVER , Replaced By: A0011840408
999
OIL FILTER , Replaced By: A0011840408
999
COVER , Replaced By: A4031801438
999
GASKET
999
FILTER ELEMENT , Replaced By: A4011800009
999
OIL FILTER , Replaced By: A0011840408
999
FLANGE HEATING CONNECTION LOCK,5 301949
999
SCREW PLUG , Replaced By: A4429970030
999
SCREW PLUG , Replaced By: A4039970230
999
FITTING , Replaced By: A0029977472
999
SCREW INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
SPRING
999
SPRING
999
SCREW , Replaced By: N910105016029
999
OIL COOLER
999
OIL FILTER , Replaced By: A4011800210
999
OIL FILTER , Replaced By: A4031801110
999
FILTER ELEMENT
999
FILTER ELEMENT , Replaced By: A0001801809
999
VALVE , NOT USED
