Поз.
Артикул
Описание
14
FLANGE FLAME START SYSTEM
44
VALVE (ELECTROMAGNET VALVE)
44
VALVE , Replaced By: A0000784749
44
VALVE , Replaced By: A0000784749
47
SHIM , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4470720186
47
SHIM ELECTROMAGNET VALVE
50
BRACKET ELECTROMAGNET VALVE
50
BRACKET ,927081
50
BRACKET ELECTROMAGNET VALVE
50
BRACKET ,927082
53
SPACER TUBE , Replaced By: A4602910350
53
BUSHING APPARATUS PLATE 9 MM, TO BE ADAPTED DURING ASSEMBLY
56
SCREW WIRING HARNESS FIXTURE AT AIR PIPE
56
SCREW , Replaced By: N308676012012
56
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
59
WASHER HEAT SHIELD TO BRACKET
62
SCREW PUMP TO BRACKET
62
HEXAGON HEAD BOLT
62
SCREW FEED LINE AND RETURN LINE
62
SCREW COVERING TO BRACKET, USED WITH MERCEDES-BENZ PLATFORM
62
SCREW , Replaced By: N304017006018
62
SCREW , Replaced By: N304017006016
62
SCREW COVER PLATE TO COVER PLATE M 6 X 12
80
GLOW PLUG , Replaced By: A9061590101
80
GLOW PLUG , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3661590401
80
GLOW PLUG , Replaced By: A9061590101
80
GLOW PLUG
80
GLOW PLUG24V
92
AIR INTAKE PIPE (TRANSVERSE INTAKE PIPE),712470
110
SCREW STOP TO BATTERY CASE
110
SCREW SUPPORT TO SIDE MEMBER
113
SPRING WASHER , Replaced By: N000137008212
113
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FUEL LINE TO ELECTROMAGNETIC VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 059404, Replaced By: A4470703232
119
LINE FROM INJECTION PUMP TO VALVE
119
LINE FROM INJECTION PUMP TO VALVE
122
SEAL CONE
125
UNION NUT
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,LEFT
128
LINE FROM SOLENOID VALVE TO HEATER PLUG
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,RIGHT
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,LEFT
128
LINE , Replaced By: A4410784302
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,LEFT
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,RIGHT, NOT USED
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,LEFT
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,RIGHT
128
LINE LEFT AND RIGHT
128
LINE FROM ELECTROMAGNETIC VALVE TO HEATER PLUG,RIGHT
128
LINE , Replaced By: A3660781402
128
LINE , Replaced By: A4410784202
128
LINE , Replaced By: A4410706832
131
DOUBLE TAPER RING LEAK LINE TO CYLINDER HEAD
134
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
146
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
146
HOLLOW SCREW PNEUMATIC VALVE
146
BANJO BOLT. HOLLOW SCREW OIL PRESSURE LINE ON OIL FILTER
149
FITTING 3/2-WAY VALVE,NEUTRAL POSITION, CONNECTIONS: " 1/2 "
152
SEAL RING SCREW PLUG
152
SEAL RING , Replaced By: N007603010110
155
BRACKET , Replaced By: A3014780040
155
BRACKET AT FEED PUMP,021062 WITH MERCEDES-BENZ BODY UP TO CHASSIS 037081,LESS MERCEDES-BENZ BODY UP TO CHASSIS 037066 EXCEPT FOR 036894,037055
158
ANGLE LINE MOUNTING
161
CLAMP FROM DISTRIBUTOR TO CYLINDER
161
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
161
CLAMP , Replaced By: N916016010211
161
CLAMP , Replaced By: N000000001045
161
CLAMP SENSOR CABLE TO FRONT AXLE
161
CLAMP CABLE HARNESS MOUNTING
164
SCREW CLAMP MOUNTING M 6X16
164
SCREWM 8X125, FROM ENGINE 706242-999999 YEAR OF MANUFACTURE 1982-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
164
SCREW BRACKET TO TAIL LAMP BRACKET
164
SCREW BRACKET TO DISC WHEEL M 10X16,D 315832
164
HEXAGON HEAD BOLT. SCREW BATTERY MOUNTING M5X12
167
WASHER BOOT TO CAB FLOOR
167
WASHER FROM TERMINAL BOX TO CHARGING AIR PIPE
167
WASHER , Replaced By: N000433005304
170
NUT , Replaced By: N913023006001
170
NUT CABLE TO ALTERNATOR,4 477130
170
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
170
NUT RELAY TO BRACKET M5
239
SENDER UNIT TEMPERATURE SWITCH, 442 792988 447 055639
239
SWITCH,AUTOMATIC TEMPERATURE SWITCH, 442 792987 447 055638
239
SWITCH,AUTOMATIC (TEMPERATURE SWITCH)
251
DOUBLE TAPER RING LEAK LINE TO CYLINDER HEAD
251
DOUBLE TAPER RING FUEL LINES TO HEATER PLUGS
254
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
257
SCREW PLUG COOLING WATER DRAIN AT OIL COOLER
260
CLAMP SENSOR CABLE TO BRACKET
260
CLAMP LINE TO SIDE MEMBER
263
SCREW PUMP TO BRACKET M 6X20
263
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
266
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
266
NUT , Replaced By: N913023006001
269
BUSHING FUEL LINE FIXTURE
272
INSULATOR , 940 10/50,20/60 220789 EXCEPT FOR 219279-219424,219432-219597,219606-219813,219821-219969,219977-220170,220176,220177,220363-220729. 940 12/52,22/62 008445
275
KNURLED NUT. NUT
281
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
281
BRACKET , Replaced By: A3604292940
281
BRACKET , Replaced By: A3604292440
287
LOOM TIE , Replaced By: A0019978390
287
LOOM TIE , Replaced By: A0019978390
287
LOOM TIE LINE MOUNTING 280 MM
290
HOLLOW SCREW COOLING WATER LINE TO CYLINDER CRANKCASE
999
VALVE HOLLOW SCREW,082519
999
VALVE (ELECTROMAGNET VALVE) 24 V
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
PARTS KIT TWO PIN JACK CONNECTOR
999
BRACKET FILLER NECK,4 400466
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
FLANGE TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
999
BRACKET TWO-WAY VALVE
999
LINE FROM INJECTION PUMP TO VALVE 700 MM
999
BURNER , NOT USED
999
SEAL TO LOCK THE BORE MEANT FOR FLAME START SYSTEM
999
BRACKET ELECTROMAGNET VALVE, NOT USED
999
LINE5X1X1100, NOT USED
999
SCREW PLUG , Replaced By: A1119970330
999
BRACKET BRACKET TO LONGITUDINAL INTAKE PIPE,064377
999
PLUG SOCKET , Replaced By: A0025403481, +001A0025408181
999
STIFFENING (PARTS KIT),TEMPERATURE SWITCH, 402 779887 447 055370
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N914146006102
999
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
999
NUT , Replaced By: N913023006001
999
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
