Поз.
Артикул
Описание
5
PROTECTIVE PLATE ENGINE PROTECTIVE PLATE
8
MOUNTING ANGLE LEFT
11
MOUNTING ANGLE RIGHT
14
SCREW BRACKET TO CROSS CONNECTION STRUT
14
SCREW , Replaced By: N304017008034
17
NUT SWITCH TO FLOOR PLATE
20
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
23
WASHER RADIATOR TO RUBBER MOUNTING
23
WASHER , Replaced By: N000125010532
26
NUT AIR CLEANER ELEMENT
29
PROTECTIVE PLATE
32
SCREW STEERING SUPPORT TO FRAME M 14X50
35
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
35
WASHER , Replaced By: N000125015019
38
NUT STEERING SUPPORT TO FRAME
38
NUT , Replaced By: N910113014000
