Поз.
Артикул
Описание
3
THREADED CONNECTION. SCREW CONNECTION OIL DISTRIBUTION
5
THREADED CONNECTION COMPRESSED AIR LINE TO WHEEL HUB
5
SCREW CONNECTION COMPRESSED AIR LINE TO WHEEL HUB, Replaced By: N000000006458
23
NUT. UNION NUT LINE CONNECTION
26
CUTTING RING. GLAND LINE CONNECTION
29
UNION NUT LINE CONNECTION
29
UNION NUT LINE CONNECTION, Replaced By: N000000006239
32
GLAND , Replaced By: A0019901967
32
SEAL CONE LINE CONNECTION
35
HOSE DELIVERY LINE, 082855 908101
35
HOSE DELIVERY LINE
38
HOSE (RETURN LINE),FROM STEERING TO OIL TANK
41
PIPE RETURN LINE
44
LINE COOLING LINE 200GE-300GE
50
LINE FROM COOLING LINE TO POWER STEERING PUMP
59
HOSE CLAMP LINE MOUNTING
59
CLAMP , Replaced By: A0059970190
74
SCREW , Replaced By: N304017006016
74
SCREW PUMP TO BRACKET
83
NUT BALL PIVOT TO LEVER
89
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
89
WASHER COMPRESSED AIR LINE TO BRACKET
92
WASHER COMPRESSED AIR LINE TO BRACKET
92
WASHER , Replaced By: N009021006208
95
SCREW STRUTS TO SIDE MEMBER WITH ANGLE
98
WASHER
101
NUT STRUT TO PROPELLER SHAFT BEARING BRACKET
104
PLATE STEERING TO FRAME
