Поз.
Артикул
Описание
10
FLAP TAILGATE
20
HINGE TAILGATE
25
SPACER
30
SCREW
40
SERRATED WASHER TAILGATE
40
SERRATED WASHER
50
SCREW PIPE CLAMP
60
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
70
HINGE TAILGATE
80
HINGE TAILGATE
90
BOLT HINGE
110
STOP TAILGATE
120
RIVET PLATFORM SIDE AND END PANELS
130
HANDLE TAILGATE
140
LEVER
140
LEVER , Replaced By: A4607430118
150
LOCK PLATE RELEASE LEVER TO SHAFT
160
SPRING
170
WASHER PUMP TO CONSOLE
180
ELECTRIC MOTOR TAILGATE LOCKING MECHANISM, X 21418720130726
210
BOLT PULL ROD,ON THE RIGHT
220
PAD REAR LID LOCK
230
NUT SPRING-LOADED PUSH ROD
240
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
250
LOCK REAR PANEL DOOR
260
SCREW CONNECTOR
270
WASHER COMPRESSED AIR LINE TO BRACKET
290
ROD LEFT
290
ROD
300
ROD RIGHT
310
SPRING LEFT CUSHION FRAME
320
SPRING LOCK ACTUATION
340
ROD TAILGATE LOCKING MECHANISM
350
LOCK REAR PANEL DOOR LOCK
360
BRACKET
370
HEXALOBULAR BOLT GAS CARTRIDGE TO ROOF FRAME, LEFT M5X10
370
SCREW. HEXALOBULAR BOLT COVER TO MOUNTING FRAME M5X12
380
WASHER MOUNTING LEDGE LEFT AND RIGHT
390
PAD960 MM, ORDER BY THE METER
400
STRIKER LOCK,LEFT & RIGHT
410
STOP
420
SCREW ON STOP M5X20, X 17916820081121
420
SCREWM5X20
430
TOOTHED WASHER
440
COVER TO TAILGATE
450
COVER
460
HINGE
470
RIVET HINGE TO COVER
480
RIVET PLATFORM SIDE AND END PANELS
490
SHELL COVERING TO TAILGATE
500
RIVET RESERVOIR TO FIRE WALL
510
PLATE UNDER SHELL-TYPE HANDLE
520
PAWL
530
BUSHING
540
RIVET GRIP RAIL MOUNTING
550
HANDLE AT MOUNTING PLATE AND COVERING
560
RECESS HANDLE
570
SPRING , Replaced By: A1235860078
580
HANDLE
590
BALL DRIVE SHAFT
610
BOLT RIGHT SEAT M5X8
610
SCREW STEP SWITCH AM 5X6,5 259580
620
WASHER BOOT TO CAB FLOOR
630
SEAL SEALING FRAME
640
COVER SOUND INSULATION
