Поз.
Артикул
Описание
5
COMPRESSOR REFRIGERANT COMPRESSOR
8
COUPLING , Replaced By: A3735527308
116
SCREW SHIFTING ROD TO JOINT
119
WASHER BRACKET TO COVERING
119
WASHER , Replaced By: N009021010209
122
NUT , Replaced By: N910113010000
125
MOUNTING PLATE COMPRESSOR TO MOUNTING PLATE
128
SELF-ALGN.ROLLER BEARING
131
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
131
SCREW , Replaced By: N304017008016
131
SCREW , Replaced By: N304017008039
134
WASHER PLATE TO BASE PLATE, FIXTURE REFRIGERANT COMPRESSOR
137
SUPPORTING PLATE REFRIGERANT COMPRESSOR, FIXTURE REFRIGERANT COMPRESSOR
140
SCREW BRACKET TO SIDE MEMBER M 12X40
143
WASHER LEAF SPRING TO STRUT
146
NUT END PIECE TO EXHAUST PIPE
146
NUT BRACKET TO LEFT SIDE MEMBER
149
CYLINDER BELT TIGHTENER
152
UNIVERSAL JOINT CYLINDER, FIXTURE REFRIGERANT COMPRESSOR
155
MUFFLER CYLINDER, FIXTURE REFRIGERANT COMPRESSOR
158
BEARING BRACKET CYLINDER, FIXTURE REFRIGERANT COMPRESSOR
161
BRACKET CYLINDER TO BEARING BRACKET, FIXTURE REFRIGERANT COMPRESSOR
164
SCREW PIPE CLAMP
164
SCREW , Replaced By: N304017008021
167
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
BRACKET BRACKET TO REFRIGERANT COMPRESSOR, FIXTURE REFRIGERANT COMPRESSOR
173
SCREW CLUTCH TO FLYWHEEL
176
WASHER RADIATOR TO RUBBER MOUNTING
176
WASHER , Replaced By: N000125010532
179
HOSE , FIXTURE REFRIGERANT COMPRESSOR
182
CLAMP LINES TO BRACKET
182
CLAMP , Replaced By: N916016012201
185
SHUT-OFF COCK ,KAO 525/93
188
SCREW OIL PUMP HOUSING M6X35
188
SCREW OIL LINES TO ENGINE,001498
191
TOOTHED WASHER MASKED STOP LAMP
194
VALVE (PRESSURE VALVE), FIXTURE REFRIGERANT COMPRESSOR
197
FITTING
200
FITTING
203
FITTING , Replaced By: N003901006007, +001N007603010404
206
SEAL RING
209
V-BELT REFRIGERANT COMPRESSOR
209
V-BELT , Replaced By: A0119978892
209
V-BELT , Replaced By: A3739977292
