Поз.
Артикул
Описание
35
VALVE FRONT AXLE LEVEL ADJUSTMENT BOSCH
38
VALVE PNEUMATIC SUSPENSION BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
38
VALVE TRAILING AXLE SELF-LEVELLING DEVICE
41
VALVE INTAKE
44
VALVE EXHAUST
47
SHAFT87 MM
50
LEVER (PARTS KIT)
53
REPAIR KIT
56
SCREW VALVE TO BRACKET, Replaced By: N304014008002
59
WASHER , Replaced By: N000125008443
62
NUT BRACKET TO SIDE MEMBER
65
FITTING LINE CONNECTION, Replaced By: N000000006446
68
VALVE LEVEL ADJUSTMENT VALVE,CONNECTION: "10"
71
SEAL RING LINE CONNECTION
71
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
74
ELBOW FITTING LINE CONNECTIONS
77
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
80
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
83
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
86
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
89
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
98
ROD , Replaced By: A3073200389
98
ROD , Replaced By: A3073200389
101
NUT , Replaced By: N304032008006
104
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
104
BALL PIVOT , Replaced By: N071803013102
107
BALL SOCKET BRAKE POWER REGULATOR CONTROL,5 574483
110
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
113
NUT BRACKET TO SIDE MEMBER
113
NUT , Replaced By: N304032008006
116
BRACKET OPERATING ROD
999
SEAL RING 3/2-WAY VALVE
