Поз.
Артикул
Описание
38
LINE FEED AND RETURN LINES TO FUEL TANK 10X0.7 MM, LENGTH AVAILABLE 25.000 MM
41
LINE FEED & RETURN 10X1 MM, LENGTH AVAILABLE: 3000 MM
44
NUT. UNION NUT RETURN
44
NUT. UNION NUT LINE CONNECTION
47
BANJO UNION FEED LINE AND RETURN LINE,842222, 001-041
50
BALL-TYPE NIPPLE. SEAL CONE , Replaced By: A3449907067
53
FITTING , Replaced By: N915008008402
53
FITTING OIL LINES
56
SEAL RINGTO 000 553 03 05,000 553 18 05,
59
CUTTING RING. GLAND LINE CONNECTION
62
HOSE RETURN
65
SEALING RING. SEAL RING ENGINE BREATHING
68
FITTING (PARTS KIT),LINE RUPTURE
68
CONNECTION FITTING , Replaced By: A0049971672
71
HOLLOW SCREW FUEL LINE TO FUEL FILTER
74
HOSE LEAK LINE
77
HOSE FUEL RETURN LINE
80
CLAMP LINE MOUNTING
83
SCREW CAB FLOOR COVERING M 6X25
86
NUT , Replaced By: N913004006001
86
NUT , Replaced By: N913004006001
89
BRACKET FUEL LINES TO BRACKET
92
CLAMP , Replaced By: N916016010211
92
CLAMP , Replaced By: N916016010211
95
SCREW CAB FLOOR COVERING M 6X25
95
SCREW CAB FLOOR COVERING M 6X25
98
WASHER , Replaced By: N009021006208
101
NUT , Replaced By: N913004006001
105
FITTING CONNECTION TO HEATER UNIT
107
CLAMP FROM FUEL FILTER TO FUEL TANK
999
BASE , Replaced By: A3142030084
999
CLAMP
999
BRACKET RADIATOR BASE FRAME
999
LOCKING CONE REAR DOOR CLOSING SYSTEM
