Mercedes N912004010102 - КОЛЬЦО ПРУЖИННОЕ

207 D/208 D 601.318

24 ENGINE SUSPENSION - 001 ENGINE REAR MOUNTING, UP TO IDENT NO.240106 AND FROM IDENT NO.500001-556499

Поз.
Артикул
Описание
5
A6013112651
TRUSS INSIDE LEFT
5
A6013112551
TRUSS INSIDE RIGHT
9
A6013110860
REINFORCEMENT OUTSIDE LEFT
9
A6013110960
REINFORCEMENT OUTSIDE RIGHT
13
A6013111360
REINFORCEMENT FRONT RIGHT
13
A6013111260
REINFORCEMENT FRONT LEFT
17
A6013100291
STIFFENING RIGHT
17
A6013100391
STIFFENING LEFT
21
A6013100491
STIFFENING SHORT
23
A6113100091
STIFFENING LEFT TOP
23
A6113100191
STIFFENING RIGHT TOP
25
A6014610335
CONSOLE (STEERING BRACKET), INSTALL AS ADDITIONAL REINFORCEMENT UP TO CHASSIS 044324
25
A6014610235
CONSOLE (STEERING BRACKET)
29
N304017010036
SCREW BRACKET TO FRAME SIDE MEMBER
31
N000933010328
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
33
N912004010102
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
37
N000125010518
WASHER , Replaced By: N000125010532
37
N000125010532
WASHER RADIATOR TO RUBBER MOUNTING
41
N910123010001
NUT TRAILER COUPLING TO REAR CROSS MEMBER
