Поз.
Артикул
Описание
7
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
8
UNION NUT
9
GLAND , Replaced By: A0019901667
9
SEAL CONE
10
ELBOW FITTING CAB FLOOR
12
LOCK WASHER FITTING TO BRACKET
14
NUT FITTING TO CAB FLOOR
16
LINE , Replaced By: A6255532457
16
LINE FITTING,HYDRAULIC HOSE,CONNECTOR,ELBOW FITTING,PLATFORM DUMPER VALVE
18
UNION NUT
20
GLAND , Replaced By: A0019901667
20
SEAL CONE
22
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
23
BRACKET PIPE LINE TO SHOCK ABSORBER BRACKET,5 360279
24
BRACKET OIL DELIVERY LINE
26
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
28
CLAMP LINE MOUNTING
30
SHEET METAL SCREW OIL LINE MOUNTING
30
SHEET METAL SCREW , Replaced By: N007981004258
37
LOOM TIE LINE MOUNTING
37
LOOM TIE LINE MOUNTING 280 MM
40
SENDER UNIT DUMPER VALVE
46
FITTING 3/2-WAY VALVE,CONNECTION: "30"
47
SEAL RING LINE CONNECTION
47
SEAL RING PNEUMATIC VALVE
47
SEAL RING , Replaced By: N007603010110
50
BRACKET SENDER UNIT
54
PLATE BRACKET TO CAB FLOOR
58
SCREW VALVE TO BRACKET M 8X55
58
SCREW , Replaced By: N304017008043
62
SCREW , Replaced By: N304017006020
62
SCREW LICENSE PLATE TO BRACKET
64
WASHER COMPRESSED AIR LINE TO BRACKET
64
WASHER , Replaced By: N009021006208
66
NUT , Replaced By: N913004006001
66
NUT PUMP TO BRACKET
80
GUMMED LABEL AT BRACKET
80
GUMMED LABEL AT BRACKET
85
HOSE , Replaced By: A0019979752
85
HOSE , Replaced By: A0149973482
85
HOSE HIGH PRESSURE
86
BRACKET. LOCK , Replaced By: A6525040038
86
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
999
BRACKET CAB,BOTTOM
999
BRACKET DRIVER'S AIR-CUSHIONED SEAT COMPRESSED-AIR LINE
999
BRACKET , Replaced By: A3956190640
999
BRACKET SENSOR CABLE TO FRONT AXLE
999
HOSE , Replaced By: A0149973482
