Поз.
Артикул
Описание
203
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
399
VALVE (RELAY VALVE),PARKING BRAKE WABCO,ZAN 493/89
399
VALVE (RELAY VALVE) WABCO
399
VALVE (RELAY VALVE) GRAU
399
VALVE (RELAY VALVE) BOSCH
399
VALVE (RELAY VALVE) KNORR
408
VALVE SEATGRAU
411
GASKET34X2X6 MM,GRAU
414
SEAL RING22.3X2.4 MM,GRAU
417
SEAL RING28X2 MM,GRAU
420
SEAL RINGTO 000 429 28 95,GRAU
423
SEAL RING86X2 MM,GRAU
429
VALVEBOSCH
429
REPAIR KIT , Replaced By: A0004201071
429
REPAIR KIT , Replaced By: A0004301109
429
REPAIR KITKNORR
429
REPAIR KITTO 002 429 92 44,ZAN 493/89
429
REPAIR KITWABCO
429
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
434
NUT , Replaced By: N913004008001
438
BRACKET RELAY VALVE,5 484806
441
SCREW BRACKET TO SIDE MEMBER
444
NUT STRAP TO BRACKET
450
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
453
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
456
O-RING CHECK VALVE TO AIR RESERVOIR
459
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
462
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
465
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
468
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
471
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
474
HOSE FRONT AND REAR AXLE BRAKE CYLINDERS 11 MM
477
UNION NUT LINE CONNECTION
477
UNION NUT LINE CONNECTION, Replaced By: N000000006239
480
GLAND , Replaced By: A0019901967
480
SEAL CONE LINE CONNECTION
481
FITTING DIAPHRAGM CYLINDER,CONNECTION:
483
FITTING DIAPHRAGM CYLINDER,CONNECTION:
489
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
493
HOLLOW SCREW FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "1"
496
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
499
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
510
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
513
BANJO UNION BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
516
VALVE PARKING BRAKE KNORR
516
VALVE PARKING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
516
VALVE PARKING BRAKE WABCO
522
HANDLETO 001 430 08 81,BOSCH
522
HANDLETO 002 430 29 81,WABCO
525
HANDLETO 001 430 17 81,KNORR
528
PROTECTIVE CAPTO WABCO
528
PROTECTIVE CAPTO BOSCH
534
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
537
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
540
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
549
REPAIR KITTO 001 430 56 81,001 430 57 81
549
REPAIR KITBOSCH
549
REPAIR KIT , Replaced By: A0034303181
552
SCREW PARKING BRAKE VALVE TO WINDOW SILL
555
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
558
HOLLOW SCREW FUEL LINE TO FEED PUMP
558
HOLLOW SCREW , Replaced By: N915036010108
561
SEAL RING FUEL LINE TO FEED PUMP
564
PLUG TO PLUG THE BORES
999
REPAIR KITTO 001 430 18 81/78 81
