Поз.
Артикул
Описание
6
ACCELERATOR PEDAL , Replaced By: A6243000304
6
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
9
SCREW ACCELERATOR PEDAL
12
BALL PIVOT ACCELERATOR PEDAL,4 859026
12
BALL PIVOT LOAD SENSOR
15
NUT PUMP TO BRACKET
15
NUT , Replaced By: N913004006001
18
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
18
SHIM ACCELERATOR PEDAL
21
BOOT ACCELERATOR PEDAL
21
BOOT ACCELERATOR PEDAL,4 859957
24
SCREW ACCELERATOR PEDAL TO CAB M 6X25
27
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
28
SERRATED WASHER ACCELERATOR PEDAL TO CAB, ELIMINATED,NO LONGER REQUIRED
30
SCREW PEDAL STOP TO CAB FLOOR
30
SCREW VALVE TO BRACKET, Replaced By: N304014008002
33
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
36
STOP ACCELERATOR PEDAL
39
BALL SOCKET ROD TO ACCELERATOR PEDAL
42
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
45
BEARING TUBE CONTROL SHAFT,5 151594
45
BEARING TUBE ,5 151593, Replaced By: A6153000021, +001A6153000020
48
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
51
SHAFT CONTROL,5 151594
51
SHAFT ,5 151593, Replaced By: A6153000020, +001A6153000021
54
BALL PIVOT CONTROL SHAFT
57
LEVER (CONTROL LEVER)
60
BALL PIVOT CONTROL SHAFT
63
CLAMPING SLEEVE BEARING TUBE
66
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
66
SCREW , Replaced By: N304017008016
69
NUT , Replaced By: N913004008001
69
NUT BRACKET TO BRACKET
75
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
78
BALL SOCKET PULL ROD TO LEVER
81
NUT BALL PIVOT TO LEVER
84
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
90
BEARING BRACKET INTERMEDIATE LEVER
90
BEARING BRACKET ,5 181099, Replaced By: A6203000436, +002A6153010088
93
LEVER , Replaced By: A3973000028
93
LEVER INTERMEDIATE BEARING
99
BALL STUD. BALL PIVOT TOP B10X4,5 MM
105
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
COVERING INTERMEDIATE BEARING
108
COVERING , Replaced By: A6153010088
111
LOCK PLATE INTERMEDIATE BEARING
114
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
114
SCREW CENTRAL LOCK TO CAB M 10X16
114
SCREW , Replaced By: N910105010009
115
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
118
NUT EXHAUST PIPE TO SIDE MEMBER
118
NUT , Replaced By: N910113010000
120
ROD FROM INTERMEDIATE LEVER TO ENGINE
122
BALL SOCKET ROD TO BALL PIVOT
124
NUT INTERMEDIATE SPEED STOP
126
SECURING CLIP. CIRCLIP
128
PIN ROD TO LEVER
130
WASHER BRACKET TO CROSS MEMBER
132
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
134
SPRING WASHER , Replaced By: N000137008212
137
MANUAL CONTROL IDLING ADJUSTMENT
138
GUIDE MANUAL CONTROL
140
KNOB , Replaced By: A6153020001
140
KNOB MANUAL CONTROL
143
FITTED WASHER MANUAL CONTROL
143
LOCK , Replaced By: N000988030003
146
NUT MANUAL CONTROL
148
WIRE CABLE IDLING ADJUSTMENT
150
CLAMPING PIECE FLEXIBLE SHAFT TO CAB FIRE WALL
151
CLAMPING PIECE FLEXIBLE SHAFT TO FRAME SIDE MEMBER
152
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X40
152
SCREW CONNECTOR
153
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
154
NUT AT FILTER BRACKET
154
NUT , Replaced By: N913004006001
156
BRACKET , Replaced By: A3813020240
156
BRACKET
158
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
158
SHEET METAL SCREW , Replaced By: N914031005208
164
SCREW COVER PLATE TO BRACKET
164
SCREW AT FILTER BRACKET
165
NUT AT FILTER BRACKET
165
NUT , Replaced By: N913004006001
166
CLAMP ,K 147121, Replaced By: N000000000319
167
SCREW HOSE TO CAB M 6X25
167
SCREW LINE MOUNTING
168
NUT BALL PIVOT TO LEVER
169
BRACKET WIRE CABLE
170
SCREW GROUND STRAP TO ENGINE
170
SCREW GROUND STRAP TO ENGINE
171
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
176
CLAMP ,K 147121, Replaced By: N000000000319
179
SCREW HOSE TO CAB M 6X25
179
SCREW , Replaced By: N304017006020
185
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
190
GROMMET WIRE CABLE THRU WINDOW SILL
193
BRACKET WIRE CABLE TO FRAME SIDE MEMBER, 415 5 014669 416 5 000516 417 4 972024
196
CLAMPING PIECE CABLE TO BRACKET
199
SCREW BRACKET TO CROSS MEMBER M 6X35
199
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
202
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
205
NUT AT FILTER BRACKET
205
NUT , Replaced By: N913004006001
999
SCREW , Replaced By: N304017012020
999
NUT BRACKET TO LEFT SIDE MEMBER
