Поз.
Артикул
Описание
10
STRAINER TURBOCHARGER OIL FEED
160
GASKET CONNECTOR TO EXHAUST MANIFOLD
160
GASKET TURBOCHARGER TO EXHAUST MANIFOLD
160
GASKET TURBOCHARGER TO EXHAUST MANIFOLD
190
SCREW THROTTLE HOUSING TO EXHAUST GAS TURBOCHARGER
190
SCREW CONNECTING PIPE TO EXHAUST BRAKE
190
CAP BOLT. SCREW BUMPER TO BRACKET,5 398606
190
SCREW , Replaced By: N000912010225
190
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD
190
SCREW TURBOCHARGER TO EXHAUST LINE,LEFT & RIGHT
196
LOCK PLATE TURBOCHARGER TO EXHAUST MANIFOLD
198
WASHER RADIATOR TO RUBBER MOUNTING
200
WASHER VIBRATION ABSORBER TO BRACKET
200
WASHER , Replaced By: N000433010510
202
NUT , Replaced By: N913023010002
202
NUT
202
NUT END PIECE TO EXHAUST PIPE
202
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
336
CONNECTING PIPE TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
336
CONNECTING PIPE EXHAUST GAS TURBOCHARGER TO CHARGING AIR LINE
336
CONNECTING PIPE TURBOCHARGER TO EXHAUST LINE,LEFT & RIGHT
336
CONNECTING PIPE
338
SEAL RING TURBOCHARGER/CHARGE-AIR-ELBOW CONNECTION
338
SEAL RING AIR INTAKE PIPE TO TURBOCHARGER
338
SEAL RING
338
SEAL RING
338
SEAL RING TURBOCHARGER TO PIPE ELBOW
432
OIL LINE OIL FEED LINE
432
OIL LINE FEED,LEFT
432
OIL LINE FEED,LEFT
432
OIL LINE FEED,LEFT
432
OIL LINE FEED,LEFT
434
OIL LINE FEED,LEFT
434
OIL LINE FEED,LEFT
434
OIL LINE FEED
434
OIL LINE FEED,LEFT
434
OIL LINE FEED,LEFT
434
OIL LINE FEED,LEFT
438
OIL LINE RIGHT OIL FEED LINE TO TURBOCHARGER
438
OIL LINE , Replaced By: A4421802220
438
OIL LINE , Replaced By: A4421801720
438
OIL LINE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421802320
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,LEFT
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,RIGHT,010388
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,RIGHT
438
OIL LINE FEED,RIGHT
450
GASKET FLANGE TO TURBOCHARGER
450
GASKET , Replaced By: A4421870280
450
GASKET
454
FLANGE OIL FEED LINE TO TURBOCHARGER
454
FLANGE , Replaced By: A4441870245
454
FLANGE OIL DELIVERY LINE TO TURBOCHARGER,928391
454
FLANGE OIL DELIVERY LINE TO TURBOCHARGER
462
GASKET FLANGE TO TURBOCHARGER
462
GASKET
464
SPRING WASHER STEERING COLUMN BRACKET TO CAB
464
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
464
SPRING WASHER , Replaced By: N000137008212
468
SCREW , Replaced By: N304017010043
468
SCREW , Replaced By: N304017010036
468
SCREW BRACKET TO SIDE MEMBER M10X35
468
SCREW END PIECE TO EXHAUST PIPE M 10X25
468
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
468
SCREW STOP TO BATTERY CASE
468
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
468
SCREW BRACKET TO FRAME SIDE MEMBER
468
SCREW BRACKET TO CONSOLE
470
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
472
SEAL RINGTO 000 553 03 05,000 553 18 05,
474
FITTING LINE CONNECTION TO TRANSMISSION
476
FITTING HEATING WATER CONNECTION
478
FITTING (PARTS KIT),LINE RUPTURE
482
CUTTING RING. GLAND LINE CONNECTION
484
NUT. UNION NUT LINE CONNECTION
486
CUTTING RING. GLAND LINE CONNECTION
488
NUT. UNION NUT LINE CONNECTION
488
UNION NUT , Replaced By: N915017010100
488
UNION NUT LINE MOUNTING,5 9363655 812730
490
OIL LINE CYLINDER CRANKCASE TO DISTRIBUTOR
492
BULKHEAD FITTING DELIVERY LINE TO FRAME
494
NUT WEAR INDICATOR
496
FITTING OIL DISTRIBUTION
498
NUT. UNION NUT LINE CONNECTION
500
CUTTING RING. GLAND LINE CONNECTION
502
T-FITTING
536
HOLLOW SCREW FITTING INJECTION PUMP BLEEDING
538
SEAL RINGTO 000 553 03 05,000 553 18 05,
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,LEFT
542
OIL LINE FEED
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,LEFT
542
OIL LINE FEED,RIGHT
546
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
548
SEAL RINGTO 006 997 00 72
548
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
550
FITTING LINE CONNECTION TO TRANSMISSION
552
FITTING LINE CONNECTION
554
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
556
SEAL RINGTO 000 553 03 05,000 553 18 05,
560
HOLLOW SCREW FITTING LINE CONNECTION
562
SEAL RINGTO 000 553 03 05,000 553 18 05,
610
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
612
CLAMP CABLE HARNESS MOUNTING
612
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
612
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
612
CLAMP , Replaced By: N916016010211
612
CLAMP , Replaced By: N000000001045
614
SCREW , Replaced By: N304017008018
614
SCREW , Replaced By: N304017008016
614
SCREW , Replaced By: A0069909301
614
SCREW BRACKET TO SIDE MEMBER M10X35
614
SCREW CLAMP ON BRACKET
614
SCREW STOP TO BATTERY CASE
614
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
614
SCREW COVER PLATE TO COVER PLATE M 6 X 12
614
SCREW BRACKET TO APPARATUS SUPPORT
614
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
616
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
616
SPRING WASHER , Replaced By: N000137008212
618
HEXAGON NUT. NUT , Replaced By: N913023008002
618
NUT SPRING-LOADED PUSH ROD
618
NUT ENGINE MOUNTING M8
694
OIL LINE RETURN,LEFT
696
PIPE ELBOW EXHAUST GAS TURBOCHARGER OIL RETURN, LEFT
696
PIPE ELBOW SUCTION PIPE TO OIL PUMP
696
PIPE ELBOW RETURN,LEFT
696
PIPE ELBOW LEFT OIL RETURN LINE TO TURBOCHARGER
696
PIPE ELBOW EXHAUST GAS TURBOCHARGER OIL RETURN, LEFT
698
PIPE ELBOW TURBOCHARGER OIL RETURN
698
PIPE ELBOW TURBOCHARGER OIL RETURN
698
PIPE ELBOW TURBOCHARGER OIL RETURN
698
PIPE ELBOW EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
698
PIPE ELBOW EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
698
PIPE ELBOW RETURN,RIGHT
700
FLANGE OIL RETURN LINE TO EXHAUST GAS TURBOCHARGER
702
THREADED INSERT
707
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, LEFT
712
GASKET
712
GASKET HEATING PIPE TO ENGINE
712
GASKET OIL RETURN LINE TO TURBOCHARGER
714
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
714
SPRING WASHER STEERING COLUMN BRACKET TO CAB
714
SPRING WASHER , Replaced By: N000137008212
716
SCREW VALVE TO BRACKET, Replaced By: N304014008002
716
SCREW , Replaced By: N304017010030
716
SCREW BRACKET TO SIDE MEMBER M10X35
716
SCREW END PIECE TO EXHAUST PIPE M 10X25
716
SCREW 4/2-WAY VALVE TO BRACKET
716
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
716
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
716
SCREW BRACKET TO FRAME SIDE MEMBER
716
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
716
SCREW STOP TO BATTERY CASE
716
SCREW STRAP TO BRACKET
716
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
716
SCREW ON STOP M 8X65
726
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
726
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
726
OIL LINE TURBOCHARGER OIL RETURN
726
OIL LINE TURBOCHARGER OIL RETURN
726
OIL LINE OIL RETURN LINE TO OIL PAN
726
OIL LINE RIGHT OIL RETURN LINE
728
SEAL RING TURBOCHARGER OIL RETURN
754
PIPE ELBOW OIL RETURN TO TIMING CASE
754
PIPE ELBOW OIL RETURN TO TIMING CASE,LEFT
754
PIPE ELBOW
756
NUT SUCTION LINE TO OIL PUMP
756
NUT 3/2-WAY VALVE TO CAB,4 685151
756
NUT , Replaced By: N080705026003
774
EXPANSION PLUG TO PLUG AIR COMPRESSOR OPENING
774
COVER OIL RETURN TO TIMING CASE,RIGHT
776
EXPANSION PLUG TO PLUG AIR COMPRESSOR OPENING
778
OIL BAFFLE OIL RETURN TO TIMING CASE,RIGHT
780
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
780
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
780
SCREW , Replaced By: N304017008016
782
PIPE ELBOW
784
NUT SUCTION LINE TO OIL PUMP
800
SCREENING PLATE OIL RETURN TO TIMING CASE,LEFT
802
COVERING OIL RETURN PIPE
802
COVERING OIL RETURN PIPE
804
PROTECTIVE PLATE PROTECTIVE PLATE TO OIL RETURN PIPE, LEFT AND RIGHT
804
PROTECTIVE PLATE LEFT OIL RETURN LINE
806
WASHER EXHAUST MUFFLER TO STRAP
806
WASHER , Replaced By: N000125008443
808
SCREW , Replaced By: N304017008008
808
SCREW , Replaced By: N304017008016
808
HEXAGON HEAD BOLT PROTECTIVE PLATE TO BRACKET
808
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
810
WASHER BRACKET TO LEFT SIDE MEMBER
810
WASHER , Replaced By: N009021008213
