Поз.
Артикул
Описание
5
FAN 8-BLADE,WITH FLEXIBLE FAN HUB, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
ANGULAR CONTACT BEARINGTO 001 205 95 06
8
BALL BEARING , Replaced By: A0019816027
11
GASKET
14
GASKET , Replaced By: A0002060580
14
GASKET FRONT COVER
17
SCREW COVER TO FAN TO 001 205 95 06
20
PRIMARY CUPTO 002 205 1506
23
COVER FRONT TO 002 205 1506
26
CLAMPING PIECE (SLIDE)
29
LOCK AS REQUIRED 2.3 MM
29
LOCK AS REQUIRED 2.0 MM
29
LOCK AS REQUIRED 2.1 MM
29
LOCK AS REQUIRED 2.2 MM
32
SEAL RING
35
SCREW
38
FLANGE
41
AIR BAFFLE , Replaced By: A4422000195
44
BRACKET COMPRESSED AIR LINE MOUNTING
47
BRACKET AIR BAFFLE TO CYLINDER CRANKCASE
50
BRACKET , Replaced By: A4422053940
53
WASHER RADIATOR TO RUBBER MOUNTING
53
WASHER , Replaced By: N000125010532
56
SCREW , Replaced By: N304017010028
59
SCREW BRACKET TO SIDE MEMBER
59
SCREW END PIECE TO EXHAUST PIPE M 10X25
59
SCREW , Replaced By: N304017010002
62
NUT BRACKET TO SUPPORT AND TO END PIECE
62
NUT BATTERY CABLE
65
SPRING WASHER STEERING COLUMN BRACKET TO CAB
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 52 CCM,TO 000 205 58 06
