Поз.
Артикул
Описание
333
SCREENING PLATE OIL RETURN TO TIMING CASE,LEFT
333
PROTECTIVE PLATE OIL RETURN LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
333
SCREENING PLATE
333
COVERING OIL RETURN PIPE
333
PROTECTIVE PLATE LEFT OIL RETURN LINE
333
COVERING OIL RETURN PIPE
333
INSULATION EXHAUST GAS TURBOCHARGER,915019
333
SCREENING EXHAUST MANIFOLD
333
INSULATION EXHAUST GAS TURBOCHARGER
333
SCREENING PLATE SCREENING PLATE TO TURBOCHARGER
333
INSULATION EXHAUST GAS TURBOCHARGER
333
PROTECTIVE PLATE TURBOCHARGER OIL RETURN
333
PROTECTIVE PLATE PROTECTIVE PLATE TO OIL RETURN PIPE, LEFT AND RIGHT
333
PROTECTIVE PLATE OIL RETURN LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
333
PROTECTIVE PLATE OIL RETURN LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
333
INSULATION , Replaced By: A4411420123
333
SCREENING PLATE ,729101, Replaced By: A4411420023
333
SCREENING PLATE OIL RETURN
393
BRACKET , Replaced By: A4421872040
393
BRACKET , Replaced By: A4420982239
393
BRACKET , Replaced By: A4420981839
393
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 887402, Replaced By: A4411870240
393
BRACKET , Replaced By: A4420981439
393
BRACKET , Replaced By: A4420981239
393
BRACKET FUEL LINES TO INTAKE MANIFOLD
393
BRACKET FUEL LINE TO FRAME
393
BRACKET OIL RETURN TO TIMING CASE
393
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
393
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
393
ANGLE LINE MOUNTING
393
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
393
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
393
BRACKET COMPRESSED AIR LINES
393
BRACKET AT INTAKE MANIFOLD
393
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER,932306
402
BRACKET AT INTAKE MANIFOLD
402
BRACKET OIL DELIVERY LINE TO CHARGING AIR PIPE,803665
402
BRACKET OIL DELIVERY LINE TO CHARGING AIR PIPE,803665
402
BRACKET CYLINDER HEAD
402
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 613694, Replaced By: A4420981539
431
BRACKET COMPRESSED AIR LINES
431
BRACKET AT WATER PUMP, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
434
BRACKET ON ENGINE SUPPORT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
435
BRACKET ON ENGINE SUPPORT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN021874
435
BRACKET ON ENGINE SUPPORT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
437
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
440
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
440
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
441
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
441
BRACKET LINE MOUNTING
441
BRACKET LEFT OIL RETURN LINE
443
BRACKET AT INTAKE MANIFOLD
484
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
484
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
484
SCREW BRACKET TO TRANSMISSION
487
SCREW REDUCTION VALVE TO BRACKET
487
SCREW , Replaced By: A0079900801
487
SCREW HOSE TO BRACKET
487
SCREW BRACKET TO EXHAUST PIPE BRACKET
487
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
487
SCREW CLAMP TO BRACKET AND TO PIPE
487
SCREW COVER PLATE TO COVER PLATE M 6 X 12
487
SCREW PIPE CLAMP
490
SCREW PIPE CLAMP
490
SCREW CLAMP TO BRACKET AND TO PIPE
493
SCREW PIPE CLAMP
493
HEX. HEAD. SCREW PULLEY TO FAN SHAFT
493
SCREW COVER PLATE TO COVER PLATE M 6 X 12
493
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
493
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
493
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
493
SCREW BRACKET TO EXHAUST PIPE BRACKET
493
SCREW VALVE TO BRACKET
493
SCREW BRACKET TO STEERING
493
SCREW HOSE TO BRACKET
493
SCREW BRACKET TO TRANSMISSION CASE
493
SCREW BRACKET TO TRANSMISSION
493
SCREW STOP TO BATTERY CASE
500
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
500
SCREW CLAMP TO BRACKET AND TO PIPE
503
SCREW CLAMP TO BRACKET AND TO PIPE
503
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
503
SCREW , Replaced By: A0079900801
503
SCREW , Replaced By: N000933008301
503
SCREW REDUCTION VALVE TO BRACKET
503
SCREW PIPE CLAMP
557
SCREW AT SHIFT LEVER M 8 X 45,P 234011
557
SCREW END PIECE TO EXHAUST PIPE M 10X25
557
HEXAGON HEAD BOLT. SCREW BRACKET TO FRAME
557
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
557
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
557
SCREW STRAP TO EXHAUST MUFFLER
562
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
562
SCREW BRACKET TO CONSOLE
562
HEXAGON HEAD BOLT BRACKET TO BRACKET
567
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
567
SCREW VALVE TO BRACKET
567
HEXAGON HEAD BOLT VALVE TO BRACKET M8X65
567
SCREW BRACKET TO TRANSMISSION CASE
574
WASHER
580
WASHER EXHAUST MUFFLER TO STRAP
581
WASHER
584
WASHER EXHAUST MUFFLER TO STRAP
584
WASHER REAR FOGLAMP TO BRACKET
584
WASHER , Replaced By: N000125013008
585
WASHER STRUT TO CROSS MEMBER
585
WASHER COOLING WATER RETURN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
585
WASHER TORSION BAR TO BEARING BRACKET
585
WASHER RADIATOR TO RUBBER MOUNTING
585
WASHER
587
WASHER
587
WASHER EXHAUST MUFFLER TO STRAP
592
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
592
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
602
NUT LEVER TO SHIFTING SHAFT
602
NUT
607
NUT LEVER TO SHIFTING SHAFT
607
NUT
607
NUT ENGINE MOUNTING M8
607
NUT SPRING-LOADED PUSH ROD
607
NUT END PIECE TO EXHAUST PIPE
607
NUT BALL PIVOT TO LEVER
618
NUT BRACKET TO SUPPORT AND TO END PIECE
618
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
619
THREADED CHUCK BRACKET TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
622
SPACER TUBE BRACKET TO CHARGING AIR LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
622
SPACER TUBE BREATHER LINE TO SIDE MEMBER
622
BUSHING APPARATUS PLATE 9 MM, TO BE ADAPTED DURING ASSEMBLY
622
SPACER TUBE EXHAUST GAS TURBOCHARGER TO CHARGING AIR LINE,021873
622
SPACER RING BRACKET TO TIMING CASE COVER
622
SPACER TUBE , Replaced By: A4602910350
622
WASHER
630
CLAMP , Replaced By: N000000001045
630
CLAMP LINE MOUNTING SA 088202/01
630
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
630
CLAMP CABLE HARNESS MOUNTING
630
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
630
CLAMP CONNECTION OF OIL LINES
630
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
630
CLAMP DE-AERATION LINE TO CHARGING AIR TRANSVERSE PIPE
999
CLAMP , Replaced By: N000000001045
999
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
999
SCREW LEVER TO ENGINE CONTROL SHAFT
999
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
999
SCREW PLUG , Replaced By: N007604014110
999
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
WASHER BRACKET TO FRAME
999
OIL LINE OIL RETURN LINE TO OIL PAN
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
TIMING CASE
999
EXPANSION PLUG CORE HOLE 40.30 MM
999
NUT , Replaced By: N913023006001
999
TURBOCHARGERGARRETT, MAKE GARRETT AND MAKE KKK ONLY EXCHANGEABLE BY PAIRS NOT USED
999
COMPRESSOR WHEELTO 004 096 52 99, NOT USED
999
TURBINE WHEELTO 004 096 54 99
999
THRUST WASHERGARRET
