Поз.
Артикул
Описание
500
SCREENING PLATE OIL RETURN
510
SCREENING EXHAUST MANIFOLD
520
PROTECTIVE PLATE OIL RETURN LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
520
PROTECTIVE PLATE OIL RETURN LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
530
PROTECTIVE PLATE LEFT OIL RETURN LINE
530
PROTECTIVE PLATE PROTECTIVE PLATE TO OIL RETURN PIPE, LEFT AND RIGHT
660
BRACKET EXHAUST GAS TURBOCHARGER
670
BRACKET FOR COMPRESSOR HOUSING, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN021874
670
BRACKET FOR COMPRESSOR HOUSING, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN021874
680
BRACKET EXHAUST GAS TURBOCHARGER,LEFT, NOT CARRIED AS A SPARE PART
700
BRACKET ON CHARGE-AIR LINE
700
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER,932306
700
BRACKET AT WATER PUMP, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
700
BRACKET COMPRESSED AIR LINE MOUNTING SA 48042
700
BRACKET OIL RETURN TO TIMING CASE
700
BRACKET INTAKE HOSE TO FILTER
700
BRACKET AT INTAKE MANIFOLD
700
BRACKET OIL DELIVERY LINE TO OIL RETURN LINE
700
BRACKET COMPRESSED AIR LINES
700
BRACKET OIL DELIVERY LINE TO TIMING CASE COVER
700
ANGLE LINE MOUNTING
700
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 613694, Replaced By: A4420981539
710
BRACKET ON ENGINE SUPPORT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
710
BRACKET ON ENGINE SUPPORT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
710
BRACKET OIL DELIVERY LINE TO OIL RETURN LINE
720
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
730
BRACKET
730
BRACKET PROTECTIVE PLATE TO OIL RETURN PIPE, LEFT AND RIGHT, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
730
BRACKET AT CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
740
ANGLE SHIFTING DOME
740
BRACKET OIL RETURN TO TIMING CASE
740
BRACKET SCREENING PLATE TO CYLINDER HEAD COVER
750
SCREW BRACKET TO APPARATUS SUPPORT
750
SCREW , Replaced By: N910105010017
750
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
750
SCREW SPEED SENSOR TO REAR AXLE
750
SCREW STRAP TO EXHAUST MUFFLER
750
SCREW OIL RETURN LINE TO ENGINE RIGHT SUPPORT
750
SCREW BRACKET TO FRAME SIDE MEMBER
750
SCREW BRACKET TO EXHAUST PIPE BRACKET
750
SCREW COVER PLATE TO COVER PLATE M 6 X 12
750
SCREW PILLAR TO BRACKET AND TO FRONT PANEL
750
HEXAGON HEAD BOLT. SCREW BRACKET TO FRAME
750
SCREW CABLE HARNESS MOUNTING
750
HEXAGON HEAD BOLT. SCREWM 12X1,5X20 MM - TO A 202 490 08 41
750
SCREW BRACKET TO CONSOLE
750
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
750
SCREW. HEXAGON HEAD BOLT BRACKET TO TRANSMISSION CASE M12X1.75X55
750
SCREW SHOCK ABSORBER TO CONSOLE
750
SCREWM 16X25
750
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
750
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
750
SCREW LEVER TO ENGINE CONTROL SHAFT
750
SCREW , Replaced By: N914146006102
750
HEXAGON HEAD BOLT VALVE TO BRACKET M8X65
750
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
750
SCREW STOP TO BATTERY CASE
750
SCREW PIPE CLAMP
750
HEXAGON HEAD BOLT BRACKET TO BRACKET
750
HEXAGON HEAD BOLT. SCREW
750
SCREW CLAMP ON BRACKET
750
SCREW OIL SEPARATOR TO CYLINDER CRANKCASE
750
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
750
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
750
SCREW VALVE TO BRACKET
750
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
750
SCREW OIL RETURN LINE TO ENGINE LEFT SUPPORT
750
SCREW AT SHIFT LEVER M 8 X 45,P 234011
750
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
750
SCREW BRACKET TO INTAKE MANIFOLD
750
SCREW BRACKET TO TRANSMISSION CASE
760
WASHER , Replaced By: N000125008443
760
WASHER BRACKET TO CHARGING AIR PIPE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
760
WASHER
760
WASHER STRUT TO CROSS MEMBER
760
WASHER , Replaced By: N000125013008
760
WASHER EXHAUST MUFFLER TO STRAP
760
WASHER FROM TERMINAL BOX TO CHARGING AIR PIPE
760
WASHER TORSION BAR TO BEARING BRACKET
760
WASHER
760
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
760
SPACER RING BRACKET TO TIMING CASE COVER
760
WASHER , Replaced By: N000125013008
760
WASHER BRACKET AND SCREENING PLATE TO CRANKCASE,FRONT
760
WASHER COLD START SYSTEM TO BRACKET
760
WASHER COOLING WATER RETURN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
760
WASHER BRACKET TO LEFT SIDE MEMBER
760
WASHER RADIATOR TO RUBBER MOUNTING
770
NUT , Replaced By: N913023006001
770
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
770
NUT
770
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
770
NUT ENGINE MOUNTING M8
770
NUT , Replaced By: N304032008006
770
NUT LEVER TO SHIFTING SHAFT
770
NUT SPRING-LOADED PUSH ROD
780
CLAMP FUEL LINES,021787 TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
780
PIPE CLAMP HALF FUEL LINES,021787 TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
800
CLAMP OIL LINE
800
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
800
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
800
CLAMP DE-AERATION LINE TO CHARGING AIR TRANSVERSE PIPE
800
CLAMP CABLE HARNESS MOUNTING
800
CLAMP LINE MOUNTING
800
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
800
CLAMP LINE MOUNTING SA 088202/01
800
CLAMP , Replaced By: N916016010211
800
CLAMP
800
CLAMP PRESSURE REGULATOR
800
CLAMP , Replaced By: N000000001045
810
PIPE CLAMP HALF FIXTURE FOR OIL FEED LINE AND OIL FILLER PIPE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF FUEL LEAK LINES
810
CLAMP
810
PIPE CLAMP HALF FIXTURE FOR OIL FEED LINE AND OIL FILLER PIPE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF WIRING HARNESS FIXTURE AT AIR COMPRESSOR COOLANT LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF OIL DELIVERY LINE TO BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
GROMMET WIRING HARNESS FIXTURE AT AIR COMPRESSOR COOLANT LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF MOUNTING PARTS, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF WIRING HARNESS FIXTURE AT AIR COMPRESSOR COOLANT LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF FUEL LINE TO FUEL LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF FUEL LINES TO INTAKE MANIFOLD
810
PIPE CLAMP HALF OIL DELIVERY LINE TO BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF COOLING WATER LINE TO BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF OIL FILLER NECK TO BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
810
PIPE CLAMP HALF TURBOCHARGER ON LEFT BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
820
SPACER RING BRACKET TO TIMING CASE COVER
820
BUSHING FUEL LINE FIXTURE
820
SPACER TUBE EXHAUST GAS TURBOCHARGER TO CHARGING AIR LINE,021873
820
BUSHING APPARATUS PLATE 9 MM, TO BE ADAPTED DURING ASSEMBLY
820
SPACER TUBE BRACKET TO CHARGING AIR LINE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
820
SPACER TUBE BRACKET TO INTAKE MANIFOLD
820
SPACER TUBE BRACKET TO FRAME SIDE MEMBER
820
BUSHING FIXTURE FOR OIL FEED LINE AND OIL FILLER PIPE
820
SPACER TUBE , Replaced By: A4602910350
830
HEXAGON HEAD BOLT BRACKET TO NO.1 CROSS MEMBER M8X35
830
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
830
SCREW CLAMP ON BRACKET
830
SCREW , Replaced By: N304017010053
830
SCREW BRACKET TO STEERING
830
SCREW , Replaced By: N304017016011
830
SCREW , Replaced By: N000933016060
830
SCREW BRAKE CYLINDER TO BRAKE ANCHOR PLATE
830
SCREW
830
SCREW , Replaced By: N304017016011
830
SCREW SHOCK ABSORBER TO CONSOLE
830
SCREWM 16X25
830
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
830
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
830
SCREW VALVE TO TRANSMISSION CASE COVER
830
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
830
SCREW STOP TO BATTERY CASE
830
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
830
HEXAGON HEAD BOLT VALVE TO BRACKET M8X65
830
SCREW CLAMP MOUNTING M 6X16
830
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
830
HEXAGON HEAD BOLT. SCREW STARTER SWITCH TO STEERING COLUMN JACKET TUBE
830
SCREW BRACKET TO TRANSMISSION
830
BOLT. SCREW CONNECTING PIPE TO INTAKE MANIFOLD
830
SCREW COVER PLATE TO COVER PLATE M 6 X 12
830
SCREW PIPE ELBOW TO BRACKET M 10X50
830
SCREW COOLING WATER OUTLET, FROM ENGINE TO HOSE CONNECTION I
830
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
830
SCREW CLAMP TO BRACKET AND TO PIPE
830
HEXAGON HEAD BOLT. SCREW LEVER TO RELEASE SHAFT
830
SCREW CABLE HARNESS MOUNTING
830
SCREW BRACKET TO EXHAUST PIPE BRACKET
830
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
840
WASHER COOLING WATER RETURN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
840
WASHER RADIATOR TO RUBBER MOUNTING
840
WASHER
840
WASHER BRACKET AND SCREENING PLATE TO CRANKCASE,FRONT
840
WASHER EXHAUST MUFFLER TO STRAP
840
WASHER OIL DELIVERY LINE TO BRACKET, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
840
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
840
WASHER FAN SHROUD TO RADIATOR
840
WASHER
840
WASHER , Replaced By: N000125013008
850
NUT SPRING-LOADED PUSH ROD
850
NUT LEVER TO SHIFTING SHAFT
850
NUT ENGINE MOUNTING M8
850
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
850
NUT
850
HEXAGON NUT SCREENING PLATE,5 163561
850
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
850
NUT REAR SPRING TO REAR AXLE
850
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
870
THREADED CHUCK BRACKET TO CYLINDER CRANKCASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
890
ANGLE SHIFTING DOME
900
SHIM BRACKET TO LEFT SIDE MEMBER
900
BASE , Replaced By: A3142030084
999
GASKET. SEAL DE-AERATION PIPE TO ENGINE
999
HOLLOW SCREW SUCTION LINE TO OIL PUMP
999
HEXALOBULAR BOLT BRACKET AND DISTRIBUTOR TO REAR AXLE I M 10X55
999
HOSE LINE EXHAUST GAS TURBOCHARGER CONNECTION, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
HOSE LINE FROM TURBOCHARGER RIGHT TO CONNECTING PIECE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
HOSE LINE FROM CYLINDER CRANKCASE TO TURBOCHARGER, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
ROUND SECTION SEAL RING OIL FILLER NECK TO OIL PAN, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
NUT ENGINE SUPPORT TO AUXILIARY FRAME, SUPPLIED LOOSE
999
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
999
SCREW PLUG RELAY VALVE,CONNECTIONS: "23"
