Поз.
Артикул
Описание
5
SWITCH WARNING BUZZER
23
RUBBER BUFFER
26
PLUG
26
PLUG AIR INTAKE PIPE
35
THREADED CHUCK BORE IN FIRE WALL
44
SERIES RESISTOR
44
SERIES RESISTOR
44
SERIES RESISTOR *** 0.6 OHM
50
SCREW ,374026
53
SPRING WASHER ALTERNATOR CONNECTION D+
56
WASHER BRACKET TO SUPPORT
56
WASHER , Replaced By: N000125004319
59
SCREW HOOK TO BRACKET
62
NUT TACHOGRAPH TO BRACKET
65
LOCK WASHER BRACKET TO STEERING COLUMN END
68
RELAY TIME-LAG 12 V
68
RELAY TIME-LAG RELAY, 055662 903741
71
SHEET METAL SCREW BRACKET TO FLOOR PLATE
71
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
74
SCREW STEP SWITCH AM 5X10
77
SPRING WASHER ALTERNATOR CONNECTION D+
80
RELAY12 V
80
RELAY FUEL PUMP CUT-OFF
80
PULSE SENDER UNIT , Replaced By: A0035452705
83
IGNITION COIL , Replaced By: A0001582803
83
IGNITION COIL , 003 114241 007 SWEDEN 105492 007 SWITZERLAND 104788 102 356391 103 358799 105 NOT FOR SWEDEN 288917 EXCEPT FOR 290205 105 SWEDEN 268063 200 121389
83
IGNITION COIL
86
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
89
SCREW , Replaced By: N304017006020
89
SCREW LICENSE PLATE TO BRACKET
89
SCREW COVER PLATE TO BRACKET
92
WASHER COMPRESSED AIR LINE TO BRACKET
92
WASHER , Replaced By: N009021006208
95
NUT BALL PIVOT TO LEVER
98
LOCK WASHER BRACKET TO STEERING COLUMN END
98
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
101
NUT BALL PIVOT TO LEVER
101
NUT TACHOGRAPH TO BRACKET
104
SHEET METAL SCREW
107
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
110
LOCK WASHER TWO-POLE CABLE CONNECTOR
113
CABLE CONNECTOR 5-POLE
116
SCREW STEERING COLUMN MOUNTED SWITCH TO STEERING COLUMN BRACKET M4X10
122
SUPPRESSOR HOUSING IGNITION COIL
122
SUPPRESSOR HOUSING IGNITION COIL, 003 114241 007 SWEDEN 105492 007 SWITZERLAND 104788 102 356391 103 358799 105 NOT FOR SWEDEN 288917 EXCEPT FOR 290205 105 SWEDEN 268063 200 121389
125
CONTROL UNIT TRANSISTORIZED IGNITION
125
IGNITION CONTROL BOX , FROM CHASSIS JAPAN 123.023 058019
128
BRACKET SWITCH, 034824 901171
131
SCREW HOOK TO BRACKET
134
SCREW , Replaced By: N304017006020
134
SCREW LICENSE PLATE TO BRACKET
137
SCREW , Replaced By: N304017006018
137
SCREW COVER PLATE TO COVER PLATE M 6 X 12
140
NUT BALL PIVOT TO LEVER
143
LOCK WASHER BRACKET TO STEERING COLUMN END
143
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
