Поз.
Артикул
Описание
10
TACHOGRAPH
10
TACHOGRAPH
20
BULB , Replaced By: A0005453419
20
SOCKET LAMP WITH SOCKET 12 V
30
INDICATOR HOUR METER
40
GROMMET
50
GUMMED LABEL TACHOGRAPH
50
GUMMED LABEL READING IN KILOMETRES
60
BRACKET TACHOGRAPH TO CENTRAL CONSOLE
70
BRACKET TACHOGRAPH TO CENTRAL CONSOLE
80
BRACKET TACHOGRAPH,K 053739N 823754
90
NUT TACHOGRAPH TO BRACKET
100
RIVETED NUT BRACKET MOUNTING, NOT USED
110
SPRING WASHER ALTERNATOR CONNECTION D+
120
SCREW , Replaced By: N304017005002
120
SCREW LEVER TO SHAFT
130
PROTECTIVE PLATE TACHOGRAPH, FROM IDENT NO. K 074703ALSO INSTALLED ON K 062141
140
BLIND CAP TACHOGRAPH LEAD SEALING
150
SHEET METAL SCREW SETSCREW LEAD-SEALING IN TACHOGRAPH
160
FLEXIBLE SHAFT BETWEEN TRANSFER CASE AND ADAPTER GEARING
170
FLEXIBLE SHAFT BETWEEN ADAPTER GEARING AND SPEEDOMETER
180
LEAD SEAL ROCKER SWITCH, Replaced By: A0009883070
180
LEAD SEAL ROCKER SWITCH
190
ADAPTER
200
BRACKET
210
SENDER UNIT LIMIT SENDER UNIT
220
SCREW , Replaced By: N304017008016
220
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
230
SPRING WASHER , Replaced By: N000137008212
230
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
240
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
240
NUT , Replaced By: N913004008001
250
SCREW , Replaced By: N304017006016
250
SCREW PUMP TO BRACKET
260
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
270
NUT BALL PIVOT TO LEVER
380
LOOM TIE LINE MOUNTING 280 MM
999
TACHOGRAPH
