Mercedes N000125010532 - Диск

290 GDT 461.335 TO CHASSIS 144225

28 TRANSFER CASE - 015 TRANSFER CASE SUSPENSION & SHIFTING MECHANISM

Поз.
Артикул
Описание
5
A4605201442
PROTECTIVE PLATE ENGINE PROTECTIVE PLATE
8
A4605240010
MOUNTING ANGLE LEFT
11
A4605240110
MOUNTING ANGLE RIGHT
14
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
14
N000933008153
SCREW , Replaced By: N304017008034
17
N913002008004
NUT SWITCH TO FLOOR PLATE
20
N304017010028
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
23
N000125010532
WASHER RADIATOR TO RUBBER MOUNTING
26
N913002010001
NUT AIR CLEANER ELEMENT
29
A4615204542
PROTECTIVE PLATE
32
N000960014237
SCREW STEERING SUPPORT TO FRAME M 14X50
35
N000125015019
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
38
N910113014000
NUT STEERING SUPPORT TO FRAME
