Mercedes N304017008034 - Болт крепления

G 300 CDI 461.392 FROM CHASSIS 144791

28 TRANSFER CASE - 015 TRANSFER CASE SUSPENSION & SHIFTING MECHANISM

Поз.
Артикул
Описание
10
A4634601009
STEERING SHAFT , 113903
20
A4614600409
STEERING SHAFT
20
A4634600509
STEERING SHAFT
30
A4614602816
STEERING COLUMN TUBE
30
A4614602616
STEER. COLUMN JACKET TUBE
40
A1269810025
BALL BEARING
50
N912009025100
SNAP RING
60
A0009946540
SNAP RING , F264121
70
A1404620751
RING , C 014018 J 016700
80
A1404620151
RING
90
A1269931326
DISC SPRING
100
N001440025002
WASHER LEVER TO CONSOLE
110
A1404620072
NUT
120
A1404620273
LOCK
130
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
130
N304017008027
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
140
A0009979745
SEAL RING STEERING NUT BEARING 12.4X1.78 MM
150
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
170
N000000003552
HEXALOBULAR BOLT HIGH-PRESSURE EXPANSION HOSE HOLDER M8X25, A 02352720090331, Replaced By: N000000003292
180
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
190
N000000003250
WASHER BRACKET TO CAB REAR PANEL
200
A2109900604
SCREW STEERING COUPLING TO STEERING GEAR,A 166260
210
A1409900958
NUT STEERING COUPLING TO STEERING GEAR,A 166260
220
A1269900312
SCREW W HEXAGON SOCKET. SCREW STEERING WHEEL TO STEERING COLUMN
