Поз.
Артикул
Описание
5
OUTSIDE REARVIEW MIRROR ELECTRICALLY ADJUSTABLE, HEATED, LEFT
5
OUTSIDE REARVIEW MIRROR ELECTRICALLY ADJUSTABLE,HEATED,RIGHT,228476
8
MIRROR GLASS
11
HEATING FOIL
11
HEATING FOIL
14
FRAME
17
ELECTRIC MOTOR
80
OUTSIDE REARVIEW MIRROR
83
MIRROR GLASS HEATED OUTSIDE REARVIEW MIRROR 172 X 172 MM
86
FRAME
89
BRACKET RAMP MIRROR
92
CLIP OUTSIDE REARVIEW MIRROR TO DRIVER'S DOOR
95
COVERING OUTSIDE REARVIEW MIRROR TO DRIVER'S DOOR
98
PAD OUTSIDE REARVIEW MIRROR TO DRIVER'S DOOR
101
SCREW , Replaced By: N007984008044
104
BRACKET LEFT
107
PLATE
110
COVERING BEARING BRACKET
113
COVERING BRACKET
116
BRACKET RIGHT
116
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6138101214
116
BRACKET RIGHT,228476
119
EL. CABLE. ELECTRIC CABLE
122
BRACKET OUTSIDE REARVIEW MIRROR ELECTRIC CABLE
125
BRACKET OUTSIDE REARVIEW MIRROR ELECTRIC CABLE,228476
128
SCREWM8 X 16 MM
131
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
134
SEAL
137
SEAL
140
SHEET METAL SCREW PANELLING TO FABRIC RETAINING RAIL
143
SCREW
146
INSIDE REARVIEW MIRROR ELECTRICALLY ADJUSTABLE
146
INSIDE REARVIEW MIRROR MANUAL
146
INSIDE REARVIEW MIRROR
149
INSIDE REARVIEW MIRROR ADDITIONAL INTERIOR MIRROR,237347
149
INSIDE REARVIEW MIRROR
150
INSIDE REARVIEW MIRROR ADDITIONAL INTERIOR MIRROR,237348
151
INSIDE REARVIEW MIRROR ,237348
152
ADAOTER ,237348
154
BRACKET INSIDE REARVIEW MIRROR TO COVERING,237347
154
BRACKET INSIDE REARVIEW MIRROR TO COVERING
155
PLATE MIRROR TO BRACKET,237347
158
HEXAL. SKT. OVAL HD. SCR. BRACKET MOUNTING,237347
158
SCREW BRACKET MOUNTING
158
SCREWM5X20
161
WASHER SWITCH TO FIRE WALL
161
WASHER PLUG SOCKET TO BRACKET
164
WASHER , Replaced By: N009021006208
167
NUT MOUNTING FRAME TO SUPPORT M6
167
NUT CLAMP TO BRACKET
167
NUT SPRING-LOADED PUSH ROD
167
NUT , Replaced By: N913023006001
170
NUT
173
SCREW PUMP TO BRACKET
999
BEARING ,228476
