Поз.
Артикул
Описание
6
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
6
ELECTRIC CABLE FROM BATTERY I TO STARTING MOTOR,5 129698
6
POSITIVE CABLE FROM BATTERY I TO STARTING MOTOR
6
ELECTRIC CABLE FROM BATTERY I TO STARTING MOTOR
6
ELECTRIC CABLE , Replaced By: A6735460013
7
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
8
CABLE SHOE BATTERY CABLE 12-70 MM
9
ELECTRIC CABLE , Replaced By: N072551070880, +001A6205460035, +001A1115460071, +001N046234010007, +001N072332013200
9
ELECTRIC CABLE , Replaced By: N922002070000
9
ELECTRIC CABLE , Replaced By: A6735460013
9
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
12
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
15
SCREW NEG.POLE
18
CABLE SHOE BATTERY CABLE 10-70 MM
21
BOOT NEG. CABLE
24
NEG. CABLE FROM BATTERY MASTER SWITCH TO STARTING MOTOR,4 695240
24
NEG. CABLE FROM BATTERY MASTER SWITCH NEG.POLE TO STARTING MOTOR NEG.POLE,5 193594
24
NEG. CABLE FROM BATTERY MASTER SWITCH TO SIDE MEMBER
24
ELECTRIC CABLE , Replaced By: A6205401831, +001A0005468730
24
ELECTRIC CABLE , Replaced By: A6205401831, +001A0005468730
27
GROMMET LINE PASSAGE AT SIDE MEMBER 32/27 MM
30
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
30
BRACKET BATTERY CABLE MOUNTING,5 193595
30
BRACKET , Replaced By: A6205244040
30
BRACKET FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO ENGINE MOUNTING
31
SCREW , Replaced By: N304017008027
31
SCREW BRACKET TO LEFT SIDE MEMBER
31
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
32
NUT BRACKET TO SIDE MEMBER
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
NUT , Replaced By: N913004008001
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
33
SCREW DISTRIBUTOR TO CAB
34
WASHER , Replaced By: N009021006208
34
WASHER COMPRESSED AIR LINE TO BRACKET
35
NUT , Replaced By: N913004006001
35
NUT PUMP TO BRACKET
36
CLAMPING PIECE BATTERY CABLE MOUNTING
36
CLAMPING PIECE , Replaced By: A6205460244
37
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
37
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
37
CLAMP DELIVERY AND SUCTION LINES TO FRAME
39
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
39
SCREW , Replaced By: N304017006012
42
NUT , Replaced By: N913004006001
42
NUT PUMP TO BRACKET
45
WASHER , Replaced By: N009021006208
45
WASHER COMPRESSED AIR LINE TO BRACKET
47
INSULATING HOSE STARTING CABLE
48
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
51
SCREW DISTRIBUTOR TO CAB
54
LOOM TIE LINE MOUNTING 280 MM
54
LOOM TIE LINE MOUNTING
57
SWITCH (BATTERY MASTER SWITCH)
59
CYLINDER
60
KNOB BATTERY MASTER SWITCH ACTUATION
63
SEAL RING BATTERY MASTER SWITCH
66
GROMMET BATTERY CASE
69
VALVE BATTERY MASTER SWITCH ACTUATION
72
BRACKET BATTERY MASTER SWITCH
75
SCREW , Replaced By: N304017008034
78
WASHER , Replaced By: N000125008443
78
WASHER EXHAUST MUFFLER TO STRAP
81
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
84
SCREW END PIECE TO EXHAUST PIPE M 10X25
84
SCREW REAR EXHAUST PIPE TO MUFFLER
87
NUT STRAP TO BRACKET
87
NUT , Replaced By: N910113010000
88
CABLE HARNESS BRAKE PRESSURE CONTROL,CIRCUITS I & II
999
ANGLE CABLE CONNECTOR
999
CABLE CONNECTOR , Replaced By: A0015465441, +001A0009872844
999
PLUG CONNECTION POINT BEHIND REAR AXLE
999
BRACKET ELECTRIC CABLE MOUNTING
999
LAMP
999
CABLE HARNESS , Replaced By: A3095400481
999
BRACKET CENTRAL JUNCTION BOX TO BRACKET BEHIND CAB
999
PRINTED CIRCUIT PLATE
999
BRACKET BATTERY CABLE TO ENGINE MOUNTING
999
BRACKET BATTERY CABLE TO BATTERY CASE
999
PRINTED CIRCUIT PLATE , Replaced By: A6175400028
999
BRACKET BATTERY CABLE TO TRANSMISSION
999
COVER BATTERY/APPARATUS SUPPORT
999
COVER BATTERY/APPARATUS SUPPORT
