Поз.
Артикул
Описание
5
TELL-TALE LAMP LESS LENS
8
BULB TELL-TALE LAMP
11
LENS RED,5 425761
11
LENS RED,5 425760
14
LENS GREEN,5 425761
17
SWITCH ENGINE COMPARTMENT LAMP,5 220080
17
SWITCH , Replaced By: A0015450611
20
CAP REAR FOGLAMP SWITCH
23
LENS FLAME STARTING SYSTEM,5 220080
26
BULB TELL-TALE LAMP
29
SWITCH , Replaced By: A0025451207
29
SWITCH , Replaced By: A0025456907
29
SWITCH PERMANENT CURRENT CUTOFF
32
LENS FLAME STARTING SYSTEM,5 220081
35
CONTROL UNIT (CONTROL UNIT)
38
RESISTOR FLAME STARTING SYSTEM
44
BRACKET SWITCH AND SERIES RESISTOR
44
BRACKET SWITCH AND SERIES RESISTOR
47
SCREW CLAMP MOUNTING M 6X16
47
SCREW , Replaced By: N000000001146
50
NUT , Replaced By: N913004006001
50
NUT PUMP TO BRACKET
53
RELAY FLAME STARTING SYSTEM
56
FUSEA16
56
FUSE , Replaced By: N072581008101
59
SHEET METAL SCREW BRACKET TO WINDOW LEVEL
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 27X1,5 129167
999
SENDER UNIT FLAME STARTING SYSTEM
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 27X1
