Поз.
Артикул
Описание
172
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
174
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
174
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
196
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
196
REPAIR KIT PRESSURE REGULATOR WABCO
198
REPAIR KITTO 001 431 06 06,BOSCH 0 481 039 101,5 148812
200
REPAIR KITTO 001 431 12 06, KNORR 3200
203
REPAIR KIT DIAPHRAGM PART BOSCH,209
206
NUT , Replaced By: N913004008001
206
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
208
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
210
CLAMP , Replaced By: A0059970190
210
CLAMP , Replaced By: N000000000667
210
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
210
HOSE CLAMP LINE MOUNTING
212
LOOM TIE LINE MOUNTING 280 MM
214
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
215
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
216
FITTING AIR RESERVOIR,CONNECTION: "13"
218
O-RING CHECK VALVE TO AIR RESERVOIR
220
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
220
THRUST RING CHECK VALVE TO AIR RESERVOIR
222
NUT CHECK VALVE TO AIR RESERVOIR
230
AIR CLEANERWABCO
230
AIR CLEANERKNORR
230
AIR CLEANERBOSCH
230
AIR CLEANERGRAU
232
FILTER ELEMENT MINOR TO 000 429 27 95,WABCO
234
FILTER ELEMENTTO 000 429 28 95,GRAU
234
FILTER ELEMENTTO 000 429 25 95,BOSCH
234
FILTER ELEMENT MAJOR TO 000 429 27 95,WABCO
236
SPRINGTO 000 429 27 95,WABCO
238
SEAL RINGTO 000 429 25 95,BOSCH
238
SEAL RINGTO 000 429 28 95,GRAU
240
SEAL RINGTO 000 429 28 95,GRAU
240
SEAL RINGTO 000 429 25 95,BOSCH
242
DIAPHRAGMTO 000 429 28 95,GRAU
242
DIAPHRAGMTO 000 429 25 95,BOSCH
243
SEAL RINGTO 000 429 27 95, WABCO
243
SEAL RING , Replaced By: A0289972348
246
NUT CHECK VALVE TO AIR RESERVOIR
248
BRACKET AIR CLEANER,5 088361
250
SCREW , Replaced By: N304017008021
250
SCREW PIPE CLAMP
252
WASHER , Replaced By: N000125008443
252
WASHER EXHAUST MUFFLER TO STRAP
254
NUT , Replaced By: N913004008001
254
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
256
FITTING SHUTTLE VALVE,CONNECTION: "20"
258
FITTING AIR RESERVOIR,CONNECTION: "13"
258
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
260
THRUST RING CHECK VALVE TO AIR RESERVOIR
260
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
262
O-RING CHECK VALVE TO AIR RESERVOIR
999
SEAL RING , Replaced By: N007603012121
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
NUT SUCTION LINE TO OIL PUMP
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
WASHER , Replaced By: N009021005205
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
WASHER STRAP TO SUPPORT
999
STUD BOLT BRACKET TO CYLINDER BLOCK, REAR,5 171760
999
SCREW , Replaced By: A0099900101
999
SCREW , Replaced By: N000933008337
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG , Replaced By: N000908022011
999
CLAMP BRAKE HOSE
999
ELBOW FITTING , Replaced By: A0039901671
999
LINE , Replaced By: A6254293501
999
LINE , Replaced By: A6194290801
999
LINE , Replaced By: A6194290801
999
BRACKET ,5 171760
999
ADHESIVE FOIL GUIDE SIGN
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
SEAL RING , Replaced By: A0009870746
999
SEAL RING , Replaced By: A0049972248
999
SEAL RING LINE CONNECTION
999
ELBOW FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20", Replaced By: A6209900071
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
PLUG
999
CONNECTOR REPAIR SIZE
999
SEALING CORDTO 000 429 27 95, WABCO
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
PISTONTO 001 431 83 05,WABCO
999
VALVEWABCO
999
FILLER RINGTO 001 431 83 05,WABCO
999
BREATHER PIPETO 001 431 83 05,WABCO
999
REPAIR KIT SEAL RING BOSCH,209
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 000 429 26 95,KNORR
999
DIAPHRAGM
999
DIAPHRAGM , Replaced By: A0004290745
999
THRUST RING SUCTION LINE TO OIL PUMP
