Поз.
Артикул
Описание
12
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
18
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
42
VALVE (3/2-WAY SOLENOID VALVE) EKS
48
PROTECTIVE CAPWABCO
56
SEAL RINGWABCO
59
GASKET KITKNORR
62
HOLLOW SCREW HEATING CONNECTION
62
HOLLOW SCREW HEATING CONNECTION
68
SEAL RING LINE CONNECTION
68
SEAL RING LINE CONNECTION
74
VALVE (PRESSURE RELIEF VALVE)
80
REPAIR KIT REDUCTION VALVE
86
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
92
SEAL RING LINE CONNECTION
98
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
104
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
104
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
110
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
112
BRACKET 3/2-WAY VALVE
122
SCREW , Replaced By: N304017008043
122
SCREW VALVE TO BRACKET M 8X55
132
SCREW , Replaced By: N304017008034
132
SCREW BRACKET TO CROSS CONNECTION STRUT
132
SCREW BRACKET TO FRAME SIDE MEMBER
134
NUT , Replaced By: N913004008001
134
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
134
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
134
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
138
NUT SUPPORT TO SIDE MEMBER
140
VALVE TWO-WAY
140
VALVE TWO-WAY
140
VALVE TWO-WAY
140
VALVE TWO-WAY
146
VALVE BODYTO 002 429 95 44
152
BALLTO 003 429 22 44
158
GASKETTO 003 429 22 44
164
FITTING RELAY VALVE,CONNECTION: "40"
170
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
176
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
182
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
188
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
194
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
200
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
200
TEST CONNECTION
206
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RINGBOSCH
999
SEAL RINGBOSCH
999
BRACKET 3/2-WAY VALVE
999
BRACKET 3/2-WAY VALVE
999
SEAL RINGBOSCH
