Поз.
Артикул
Описание
48
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
48
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
52
UNION NUT LINE CONNECTION
52
UNION NUT LINE CONNECTION
56
GLAND LINE CONNECTION
56
GLAND LINE CONNECTION
60
SLEEVE LINE CONNECTION
60
SLEEVE LINE CONNECTION
60
SLEEVE , Replaced By: N915062006000
64
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
64
BANJO UNION HEATING CONNECTION,K 169122
64
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
64
BANJO UNION HEATING CONNECTION,K 169122
88
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
88
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
97
BRAKE HOSE AT REAR AXLE
97
BRAKE HOSE AT REAR AXLE
97
BRAKE HOSE FRONT
97
BRAKE HOSE FRONT
102
BRACKET BRAKE HOSE
102
BRACKET BRAKE HOSE
104
NUT STRAP TO BRACKET
104
NUT STRAP TO BRACKET
104
NUT , Replaced By: N910113010000
124
INSULATING HOSE AIR DEHYDRATOR, ORDER BY THE METER
124
INSULATING HOSE AIR DEHYDRATOR, ORDER BY THE METER
132
GROMMET
132
GROMMET
835
LOOM TIE LINE MOUNTING
835
LOOM TIE LINE MOUNTING
838
CLIP
838
CLIP
839
CLIP ,303365
839
CLIP ,303365
843
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
843
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL WABCO
843
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL WABCO
843
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
844
VALVE PARKING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
844
VALVE , Replaced By: A0014306581
844
VALVE , Replaced By: A0024300381
844
VALVE PARKING BRAKE WABCO
844
VALVE PARKING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
844
VALVE PARKING BRAKE WABCO
845
PROTECTIVE CAPTO BOSCH
845
PROTECTIVE CAPKNORR
845
PROTECTIVE CAPTO WABCO
845
PROTECTIVE CAPKNORR
845
PROTECTIVE CAPTO WABCO
845
PROTECTIVE CAPTO BOSCH
847
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
847
COVERTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
848
BUSHINGTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
848
BUSHINGTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
849
SPACER TUBETO 001 430 08 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
849
SPACER TUBETO 001 430 08 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
850
WASHERTO 001 430 07 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
850
WASHERTO 001 430 07 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
851
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
851
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
851
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
851
PINTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
852
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
852
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
853
ACTUATING PARTTO 001 430 07 81/20 81
853
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
853
ACTUATING PARTTO 001 430 07 81/20 81
853
ACTUATING PARTTO 001 430 37 81/46 81,BOSCH, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
854
HANDLETO 001 430 08 81,BOSCH
854
HANDLE , Replaced By: A0009972777, +001A0034302881
854
HANDLE , Replaced By: A0009972777, +001A0034302881
854
HANDLETO 002 430 29 81,WABCO
854
HANDLETO 001 430 08 81,BOSCH
854
HANDLETO 002 430 29 81,WABCO
856
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
856
VALVE. REPAIR KIT HAND BRAKE LEVER TO 001 430 65 81
856
LEVER , Replaced By: A0034302881
857
PINTO 002 430 90 81
857
PINTO 002 430 90 81
858
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
858
HANDLE (PARTS KIT) TO 001 430 07 81/20 81, UP T0 BOSCH CHARACTERISTIC NUMBER 045
860
REPAIR KITTO 001 430 56 81,001 430 57 81
860
REPAIR KITTO 001 430 17 81,KNORR
860
REPAIR KITTO BOSCH
860
REPAIR KITTO 001 430 56 81,001 430 57 81
860
REPAIR KITBOSCH
860
REPAIR KITTO 001 430 58 81/59 81,WABCO, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
860
REPAIR KIT , Replaced By: A0034303381
860
REPAIR KIT , Replaced By: A0034303181
860
REPAIR KITTO 001 430 58 81/59 81,WABCO, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
860
REPAIR KITTO BOSCH
860
REPAIR KITBOSCH
860
REPAIR KITTO 001 430 17 81,KNORR
862
COVERING BRAKE VALVE
862
COVERING BRAKE VALVE
862
COVERING BRAKE VALVE
862
COVERING BRAKE VALVE
863
HOLLOW SCREW FUEL LINE TO FEED PUMP
863
HOLLOW SCREW FUEL LINE TO FEED PUMP
863
HOLLOW SCREW , Replaced By: N915036010108
864
SEAL RING FUEL LINE TO FEED PUMP
864
SEAL RING FUEL LINE TO FEED PUMP
865
SHIM AT BRAKE VALVE
865
SHIM AT BRAKE VALVE
866
WASHER EXHAUST MUFFLER TO STRAP
866
WASHER , Replaced By: N000125008443
866
WASHER EXHAUST MUFFLER TO STRAP
867
SCREW AT BRAKE VALVE
867
SCREW AT BRAKE VALVE
967
UNION NUT
967
UNION NUT
968
GLAND , Replaced By: A0019901667
968
GLAND , Replaced By: A0019901667
969
SLEEVE LEAK LINE
969
SLEEVE LEAK LINE
972
BRACKET RIGHT
972
BRACKET , Replaced By: A3104280740
972
BRACKET BRACKET TO REAR AXLE
972
BRACKET BRACKET TO REAR AXLE
972
BRACKET RIGHT
973
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
973
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
973
SCREW PIPE CLAMP
973
SCREW , Replaced By: N304017008039
973
SCREW , Replaced By: N304017008021
973
SCREW PIPE CLAMP
974
CLAMP BRAKE LINE MOUNTING
974
CLAMP BRAKE LINE MOUNTING
975
HOSE BRAKE LINE TO REAR AXLE,4 644238
975
HOSE BRAKE LINE TO REAR AXLE,4 644238
978
BRACKET AT SIDE MEMBER,503067
978
BRACKET AT SIDE MEMBER,503067
979
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
979
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
980
NUT STRAP TO BRACKET
980
NUT , Replaced By: N910113010000
980
NUT STRAP TO BRACKET
999
SCREW COVERING TO RAIL
999
CLAMP , Replaced By: N916016008200
999
BASE STRAP
999
REPAIR KIT , Replaced By: A3534200167
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM BRAKE MASTER CYLINDER TO LEFT FRONT WHEEL 1550 MM
999
HOSE BRAKE CABLE TO FORK 45 MM,556500 ALSO INSTALLED ON 553210,556146 ORDER BY THE METER
999
SPRING ,556500 ALSO INSTALLED ON 553210,556146
999
DAMPING RING
999
CONNECTOR HAND BRAKE LEVER,556500 ALSO INSTALLED ON 553210,556146
999
BEARING BODY ,556500 ALSO INSTALLED ON 553210,556146
999
SPHERICAL PIECE ,556500 ALSO INSTALLED ON 553210,556146
999
NUT , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD ,556500 ALSO INSTALLED ON 553210,556146
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
LEVER INTERMEDIATE LEVER, FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
SUPPORT ,556500 ALSO INSTALLED ON 553210,556146
999
SUPPORT UPPER PART
999
BUSHING , Replaced By: A0009973481
999
LINE WITH BEAD,10 MM
999
GASKET BRACKET TO FIRE WALL,707221
999
GASKET BRACKET TO FIRE WALL,707221
999
BRACKET BRAKE BOOSTER BRACING
999
BRACKET BRAKE BOOSTER ASSEMBLY
999
GROMMET , Replaced By: A0019877625
999
BRACKET RIGHT
999
BRACKET LEFT
999
HANDLETO 341 420 00 88
999
BRAKE LEVER
999
BEARING BRACKET HAND BRAKE LEVER, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
999
RATCHET ROD
999
PROTECTIVE PLATE
999
PROTECTIVE PLATE ,544549
999
SPHERICAL PIECE , Replaced By: A3025860242
999
PIN BRAKE PEDAL TO BRAKE BOOSTER
999
GASKET
999
CLAMP , Replaced By: A0004760436
999
SEAL RING42.52X2.62 MM,WABCO
999
SEAL RING , Replaced By: A0179979048
999
HOSE FROM RESERVOIR TO MASTER CYLINDER
999
BRAKE MASTER CYLINDER
999
BRAKE MASTER CYLINDER , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
THRUST RINGVOSS,707221
999
REPAIR KIT , Replaced By: A0034201724
999
HOSE
999
SEAL RING , Replaced By: A0009971548
999
BRAKE BOOSTER ASSEMBLY , UP TO IDENT NO. 352290 EXCEPT FOR 350368,350793,350843,350954,351074,351169,351284,351434,351903,352001,352271,352272. ALSO INSTALLED ON 352332,352759,353163,353868,354161.
999
BRAKE BOOSTER ASSEMBLY , FROM CHASSIS 018154 ALSO INSTALLED ON 017661,017829 EXCEPT FOR 018155,018156,018159,018308,018310,018315,018317,018318,018327,018350,018355. EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 533350, Replaced By: A0024305630, +001A1262920074, +001N912011008000
999
VALVE PARKING BRAKE KNORR
999
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL KNORR
999
HOSE FROM PARKING BRAKE VALVE TO ELBOW FITTING
999
SPRING , Replaced By: A0009935205
999
BUSHING , Replaced By: N915062004000
999
ELBOW FITTING , Replaced By: A0019904371
999
BANJO UNION , Replaced By: N915052006005
999
OUTER RACETO 003 429 11 44,VOSS,707221
999
HOSE , Replaced By: A0004358382
999
PISTONVOSS
999
RESERVOIR , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
CUP , Replaced By: A0015864342
999
FILLER CAP , Replaced By: A0004317633
999
FILLER CAP , Replaced By: A0004316533
