Поз.
Артикул
Описание
5
OIL FILLER NECK
5
OIL FILLER NECK , 007567
8
CAP OIL REFILLING
8
CAP OIL REFILLING
8
CAP OIL REFILLING
8
CAP , Replaced By: A0000180702
11
GASKET , Replaced By: A1020180380
11
GASKET
11
GASKETTO 352 010 01 68
14
SPACER RING
16
SCREW , Replaced By: N304017008016
16
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
18
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
18
NUT , Replaced By: N913004008001
20
HOSE FROM OIL FILTER NECK TO ENGINE
23
CLAMP , Replaced By: N000000000670
23
CLAMP
26
RUBBER SECTION AT LEFT SIDE MEMBER 85 MM
26
RUBBER SECTION , Replaced By: A0009870772
29
AIR INTAKE PIPE
29
AIR INTAKE PIPE , Replaced By: A3095201501
32
RUBBER BUFFER COVERING TO FRAME
32
RUBBER BUFFER , Replaced By: A0019875240
35
BRACKET , Replaced By: A3095282140
35
BRACKET AIR INTAKE
38
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
41
NUT
44
SCREW PIPE CLAMP
44
SCREW , Replaced By: N304017008021
47
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
50
WASHER , Replaced By: N000125008443
50
WASHER EXHAUST MUFFLER TO STRAP
56
AIR INTAKE PIPE FROM INTAKE PIPE TO AIR CLEANER
62
CLAMP , Replaced By: N000000000674
62
CLAMP HOSE 70-90X13 MM
65
AIR CLEANER , Replaced By: A0110941602
65
AIR CLEANER OIL BATH AIR CLEANER
71
FILTER ELEMENT
77
GASKET
80
GASKET
80
GASKET OUTSIDE TO 006 094 00 02,011 094 16 02
80
GASKET , Replaced By: A0010947880
95
COTTER PINTO 006 094 00 02
98
FASTENER
98
FASTENERKNECHT
98
FASTENER , Replaced By: A0000941255
98
FASTENER AIR CLEANER BOWL MANN & HUMMEL
101
SUPPORT OIL BATH AIR CLEANER TO BRACKET AT FIRE WALL
104
SCREW END PIECE TO EXHAUST PIPE M 10X25
107
NUT , Replaced By: N910113010000
107
NUT STRAP TO BRACKET
110
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
110
SCREW , Replaced By: N304017008016
113
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
116
WASHER , Replaced By: N000125008443
116
WASHER EXHAUST MUFFLER TO STRAP
140
AIR INTAKE PIPE FROM OIL BATH AIT CLEANER TO INTAKE MUFFLER
146
CLAMP HOSE 70-90X13 MM
146
CLAMP , Replaced By: N000000000674
149
HOSE WATER DRAIN
149
HOSE WATER DRAIN
152
RUBBER RING
155
AIR INTAKE PIPE
155
AIR INTAKE PIPE
158
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
161
NUT STRAP TO BRACKET
161
NUT , Replaced By: N910113010000
164
AIR INTAKE PIPE FROM MUFFLER TO INTAKE FITTING,063637
164
AIR INTAKE PIPE FROM MUFFLER TO INTAKE FITTING,063636
167
CLAMP , Replaced By: N000000000674
167
CLAMP HOSE 70-90X13 MM
999
REINFORCEMENT AIR CLEANER
999
SHIM BODY TO FRAME
