Поз.
Артикул
Описание
90
LEVER
96
BALL PIVOT
105
BEARING BRACKET
113
BOOT BEARING BRACKET TO CAB FLOOR
121
SHIM BEARING BRACKET TO CAB FLOOR
129
SCREW HANDLE TO LID
137
NUT PUMP TO BRACKET
137
NUT , Replaced By: N913004006001
145
SCREW HAND BRAKE VALVE TO BRACKET
153
PIVOT PIN LEVER TO BEARING BRACKET
160
LOCK LEVER TO BEARING BRACKET
168
SCREW BRACKET TO TAIL LAMP BRACKET
176
SPRING WASHER ALTERNATOR CONNECTION D+
184
CLAMP LINE MOUNTING
195
SHIFT LEVER
202
BALL PIVOT
210
PIVOT PIN SHIFT LEVER
218
SPRING SHIFT LEVER
226
HANDLE , 108.018,019 071883 EXCEPT FOR 071802,071873 109.016 UNTIL PRODUCTION STOP 109.056 003758 111.024,025 005065 111.026,027 002941
234
PULL ROD
242
BALL SOCKET PULL ROD
250
BALL SOCKET ROD TO BALL PIVOT
257
SNAP RING
264
NUT INTERMEDIATE SPEED STOP
271
NUT
277
SECURING CLIP. CIRCLIP
290
BRACKET
298
SCREW COVER PLATE TO BRACKET
306
SPRING WASHER LICENSE PLATE TO BRACKET
314
WASHER BRACKET TO TRANSMISSION
322
PULL ROD
322
PULL ROD , Replaced By: A3092601689
328
BALL SOCKET
510
ROD WIRE CABLE TO ENGINE, NOT USED
516
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW PIPE CLAMP
999
SCREW , Replaced By: N304017008021
999
COTTER PIN LEVER TO ROD
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SPRING LOCK RELEASE YOKE TO RELEASE BEARING
999
SEAL RING RELEASE YOKE
999
SEAL RING RELEASE YOKE
999
BEARING RELEASE YOKE
999
END COVER TOP,4 696330
999
BOOT
999
BRACKET LINE MOUNTING, TO BE ADAPTED DURING ASSEMBLY
999
PLUG BELL HOUSING,410179
999
RELEASE LEVER
999
HANDLE (GEARSHIFT LEVER KNOB)
999
BRACKET , Replaced By: A3464290340
999
COVER
999
BOOT RELEASE LEVER, UP TO CHASSIS 4 691315, FROM CHASSIS 4 691316 SEE STANDARD VERSION
999
HOUSING , Replaced By: A3142510302
999
SCREW CLUTCH TO FLYWHEEL
999
PROTECTIVE PLATE , Replaced By: A3522500055
999
FAN SHROUD RADIATOR
999
HOSE FROM THERMOSTAT TO RADIATOR
999
HOSE FROM RADIATOR TO WATER PUMP
999
RADIATORBEHR, FROM CHASSIS 611358 EXCEPT FOR 611519,611537 ALSO INSTALLED ON 610763,610832,610834,610848,610863
999
CROSS MEMBER PISTOL-GRIP HAND BRAKE NO.4, FROM IDENT NO. 556500 ALSO INSTALLED ON 553210,556146
999
ROD OVER-CENTER ACTING SPRING
999
PEDAL CLUTCH,526441
999
ROD FROM CLUTCH PEDAL TO MASTER CYLINDER,526441
999
SHIFT LEVER ,540949
999
BRACKET OUTSIDE,451350
999
BRACKET INSIDE,451350
999
BELL HOUSING , Replaced By: A3102510601
999
COVER BELL HOUSING,4 696330
999
BRACKET RIGHT
999
BRACKET LEFT
999
RADIATOR , FROM CHASSIS 611358 EXCEPT FOR 611519,611537 ALSO INSTALLED ON 610763,610832,610834,610848,610863
999
COVER COVERING TO CAB
999
PROTECTIVE PLATE , Replaced By: A3094200844
999
RATCHET ROD
999
CROSS MEMBER RADIATOR, FROM IDENT NO. 611358 EXCEPT FOR 611519,611537 ALSO INSTALLED ON 610763,610832,610834,610848,610863
999
CROSS MEMBER RADIATOR,156153 UP TO IDENT NO. 611357 ALSO INSTALLED ON 611519,611537 EXCEPT FOR 610763,610832,610834,610848,610863
999
SHIM STOP TO FLOOR BOARD, FROM IDENT NO. 556500 ALSO INSTALLED ON: 543411,543418,551588,551771,552021,552392,552551,552654,552687,552840,552846,553000,553005,553105, 553112,553264,553332,554081,554103,554213,554266,554270,554993,555186,555885,555992,556138,556169, 556181,556184,556187,556189,556194-556197,556215.
999
INTERMEDIATE PIECE FROM CLUTCH MASTER CYLINDER TO RESERVOIR
999
HOSE FROM CLUTCH HOSE TO SLAVE CYLINDER
999
SPRING RETAINER SPRING TO PUSH ROD
999
LINE , Replaced By: A3404201129
999
BOOT SHIFT LEVER BEARING COVERING
999
SPHERICAL PIECE GEARSHIFT LEVER LOWER PART,D 203092
999
STOP
999
WASHER PEDALS TO PIVOT PINS
999
SPRING RETAINER SPRING TO PUSH ROD
999
GROMMET , Replaced By: A1079970881
999
SPRING (DEAD CENTER SPRING) 35 MM
999
SPRING GEARSHIFT LEVER LOWER PART,D 209705
999
PAD , Replaced By: A1072910182
999
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
CLUTCH DISC
999
LOCK AT WATER EXPANSION TANK
999
SLAVE CYLINDER CLUTCH, FROM IDENT NO. 148037 ALSO INSTALLED ON 140555,142078
999
MASTER CYLINDER , Replaced By: A0012958706
999
RELEASE BEARING , Replaced By: A0012509315
