Поз.
Артикул
Описание
3
RADIATORBEHR,4 755510
3
RADIATORBEHR,4 755510
3
RADIATORBEHR,4 1978068 0000014 755509
12
SEAL RING FUEL LINE TO FEED PUMP
16
SCREW PLUG WATER DRAIN
21
RADIATOR CAPTO 335 500 12 03
21
RADIATOR CAPTO 335 500 12 03
21
RADIATOR CAP WITH PRESSURE RELIEF VALVE
24
GASKET O.D., 37 MM
84
RUBBER MOUNTING
87
WASHER , Replaced By: N000125010532
87
WASHER RADIATOR TO RUBBER MOUNTING
90
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
93
NUT BRACKET TO SUPPORT AND TO END PIECE
96
FAN SHROUD ,4 1978068 000001
96
FAN SHROUD ,4 1978068 000001
105
SCREW LICENSE PLATE TO BRACKET
105
SCREW , Replaced By: N304017006020
108
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
111
NUT PUMP TO BRACKET
111
NUT , Replaced By: N913004006001
114
BRACKET RADIATOR
117
SCREW PIPE CLAMP
117
SCREW , Replaced By: N304017008021
120
WASHER EXHAUST MUFFLER TO STRAP
120
WASHER , Replaced By: N000125008443
123
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
126
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
126
NUT , Replaced By: N913004008001
129
RADIATOR STRUT ,7892878 000001
129
RADIATOR STRUT ,789286
132
RUBBER RING SHOCK ABSORBER MOUNTING
135
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
138
WASHER BRACKET TO COVERING
138
WASHER , Replaced By: N009021010209
141
NUT BRACKET TO SUPPORT AND TO END PIECE
144
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
147
NUT BRACKET TO SUPPORT AND TO END PIECE
150
HOSE OVERFLOW TO 357 500 10 49
150
HOSE OVERFLOW TO 357 500 10 49
150
HOSE , Replaced By: A0189972882
156
HOSE FROM RADIATOR TO THERMOSTAT
156
HOSE FROM RADIATOR TO THERMOSTAT
162
CLAMP
162
CLAMP , Replaced By: N000000000671
168
HOSE FROM RADIATOR TO WATER PUMP,7892878 000001833479
174
LINE FROM RADIATOR TO WATER PUMP,4 822760
174
LINE FROM RADIATOR TO WATER PUMP, UP TO IDENT NO. 789286 EXCEPT FOR 662256
255
PIPE HEATING PIPE,4 822761
255
PIPE HEATING PIPE,4 7555104 822760
255
LINE HEATING PIPE,4 822761
255
LINE HEATING PIPE,7892878 0000014 755509
255
LINE HEATING PIPE,7892878 0000014 755509
255
LINE HEATING PIPE,789286 IN CASE OF REPLACEMENT,RANGE OF DELIVERY INCLUDES UP TO IDENT NO. 611235:1 SEAL RING 007603 008112,1 SCREW PLUG 007604 008100
258
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
258
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
261
CLAMP , Replaced By: N000000000667
261
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
264
CLAMP , Replaced By: A1109950401
264
CLAMP FUEL LINE TO BRACKET
264
CLAMP FUEL LINE TO BRACKET
264
CLAMP , Replaced By: A6739950001
264
CLAMP DELIVERY AND SUCTION LINES TO STEERING
264
CLAMP FEED LINE TO THERMOSTAT
267
SEAL RING FUEL LINE TO FEED PUMP
270
SEAL RINGTO 000 550 00 83
273
SCREW PLUG HEATING PIPE,6112368 0000014 375862
276
CLAMP LINE MOUNTING
279
SHIM BRACKET TO LEFT SIDE MEMBER
282
BRACKET HEATING WATER LINE
285
SCREW , Replaced By: N304017006020
285
SCREW LICENSE PLATE TO BRACKET
285
SCREW LICENSE PLATE TO BRACKET
288
NUT , Replaced By: N913004006001
288
NUT PUMP TO BRACKET
288
NUT PUMP TO BRACKET
291
CLAMP LINE MOUNTING
294
CLAMP , Replaced By: A6739950001
294
CLAMP DELIVERY AND SUCTION LINES TO STEERING
297
SCREW , Replaced By: N304017008016
297
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
300
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
303
NUT
306
CLAMP , Replaced By: A6739950001
306
CLAMP DELIVERY AND SUCTION LINES TO STEERING
309
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
312
SCREW , Replaced By: N000000001146
312
SCREW CLAMP MOUNTING M 6X16
999
CONTROL VALVE , PART NUMBER HAS BEEN CONVERTED TO THE NEW MODE OF WRITING, Replaced By: A3208350720
999
SHIM , Replaced By: A3815010495
999
CLAMP LINE MOUNTING
999
CONTROL VALVE ,611235
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3185060640
999
HOSE , Replaced By: N073379006203
999
BRACKET , Replaced By: A3185000331
999
HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 680043, Replaced By: A3145011482
999
HOSE , Replaced By: A3145010582
999
RADIATOR
999
RADIATOR
999
RADIATOR ,833480-961528, Replaced By: A3145004702, +001A3145011482, +001A3145050555, +001N900271015080
999
LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 375862, Replaced By: A3145010982
999
LINE ,7892878 000001 EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO IDENT NO. 4 375862, Replaced By: A3145001872
999
RADIATOR , ONLY APPLICABLE TO IDENT NO. 662256,681960,681966,681969,681976,682036,682038,682051,682063,682066,682081., Replaced By: A3145003402, +001A3145001472, +001A3145010782
999
RADIATOR , INAPPLICABLE TO IDENT NO. 662256,681960,681966,681969,681976,682036,682038,682051,682063,682066,682081.833479, Replaced By: A3145004702, +001A3145001672, +001A3145010782, +001A3145011482, +001A3145050555, +001N900271015080
999
LINE , Replaced By: A3145000872
999
RADIATOR , INAPPLICABLE TO IDENT NO. 662256,681960,681966,681969,681976,682036,682038,682051,682063,682066,682081.833479, Replaced By: A3145004702, +001A3145001672, +001A3145010782, +001A3145011482, +001A3145050555, +001N900271015080
999
LINE , Replaced By: A3145001072
999
LINE , Replaced By: A3145000872
999
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
999
BRACKET , Replaced By: A3124761535
999
CLAMP , Replaced By: A3129952420
999
CLAMP , Replaced By: A3609952001
999
RADIATOR FILLER CAP. RADIATOR CAP
