Поз.
Артикул
Описание
6
EXHAUST PIPE FRONT FRONT PART
11
FLANGE GASKET
16
STUD BOLT ADDITIONAL GEARBOX TO TRANSMISSION CASE M 10X30
21
NUT CONNECTING PIPE TO EXHAUST BRAKE
25
EXHAUST PIPE FRONT CENTRAL PART
29
PROTECTIVE PLATE FRONT EXHAUST PIPE
34
WASHER EXHAUST MUFFLER TO STRAP
34
WASHER , Replaced By: N000125008443
36
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
41
SCREW CLAMP TO BRACKET AND TO PIPE
45
FRONT EXHAUST PIPE REAR PART
49
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
49
CLAMP , Replaced By: N071555090502
53
SCREW END PIECE TO EXHAUST PIPE M 10X25
55
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
57
NUT BRACKET TO SUPPORT AND TO END PIECE
61
EXHAUST MUFFLER
65
EXHAUST PIPE REAR
999
999
PISTON RING
999
SPHERICAL RING
999
COVER
999
END PIECE EXHAUST OUTLET
