Поз.
Артикул
Описание
160
AIR CLEANER OIL BATH, FROM CHASSIS 001732
162
HOSE FROM THERMOSTAT TO RADIATOR FILLER NECK, ORDER BY THE METER
163
LOOM TIE ALTERNATOR BREATHING
163
CLAMP , Replaced By: N000000000671
163
CLAMP
164
INTAKE PIPE FROM AIR CLEANER TO AIR COMPRESSOR
166
HOSE
168
STRAP AIR HOSE TO ELBOW AND TO INTAKE CASE 570 MM, ORDER BY THE METER
169
LOOM TIE ALTERNATOR BREATHING
169
CLAMP , Replaced By: N000000000667
169
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
170
ELBOW FITTING
171
COMPRESSOR AIR-COOLED
177
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
178
O-RING CHECK VALVE TO AIR RESERVOIR
179
NUT CHECK VALVE TO AIR RESERVOIR
180
ELBOW FITTING LINE CONNECTION
182
SCREW
183
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
184
NUT , Replaced By: N304032008006
187
COUPLING
192
LINE FROM AIR COMPRESSOR TO CONNECTOR I 18.00 MM
194
TUBE FEED AND RETURN LINES TO OIL COOLER, LENGTH AVAILABLE 3000 MM
195
LINE FROM AIR COMPRESSOR TO PRESSURE REGULATOR 18X1,5 MM, LENGTH AVAILABLE: 3000 MM
196
UNION NUT , 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
197
GLAND , Replaced By: A0019901167
197
SEAL CONE LINE MOUNTING
198
FITTING CONNECTION "2"
199
THRUST RING , 10/20 UP TO CHASSIS 4 191895,50/60 UP TO CHASSIS 4 189545
201
SEAL RING , Replaced By: N915045015100
201
SEAL RING LINE CONNECTION
203
CLAMP LINE MOUNTING
204
CLAMP , Replaced By: A3049950120
204
CLAMP
204
CLAMP FEED LINE TO THERMOSTAT
206
BASE , Replaced By: A3142030084
206
SHIM BRACKET TO LEFT SIDE MEMBER
214
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
215
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
216
UNION NUT BUTT SCREW CONNECTION
217
GLAND LINE CONNECTION
218
THRUST RING BUTT SCREW CONNECTION
219
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
220
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
222
BRACKET
223
CLAMP LINE MOUNTING
225
SCREW COVER PLATE TO BRACKET
226
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
227
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
228
NUT BALL PIVOT TO LEVER
229
LINE , Replaced By: A0004296201
229
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
230
UNION NUT
231
GLAND , Replaced By: A0019901667
233
CLAMP LINE MOUNTING
235
SCREW COVER PLATE TO BRACKET
236
WASHER HEAT SHIELD TO BRACKET
237
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
238
NUT BALL PIVOT TO LEVER
590
T-FITTING CONNECTION TO STOP LIGHT SWITCH,002507
596
SWITCH EXHAUST BRAKE,K 251255
999
999
BUSHING
999
THRUST WASHER
999
999
CLAMP , Replaced By: A3609950101
999
FITTING AIR BRAKE CYLINDER,549430
999
ROLLER , Replaced By: A3014200039, +002A0039971548
999
PLUG PROTECTIVE PLATE
999
BUSHING
999
VALVE , Replaced By: A0001314204
999
SPRING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
CLAMP LINE MOUNTING
999
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
999
BUSHING
999
SCREW PLUG SOCKET TO COVERING
999
999
COTTER PIN BATTERY COVERING TO A 386 540 70 14
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PIN STRAP TO CONSOLE 20 L
999
COTTER PIN REAR PANEL TO SUBSTRUCTURE
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PIN STRAP TO SUPPORT
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN COUPLING FLANGE TO P.T.O.
999
COTTER PIN HYDRAULIC CYLINDER TO SWIVEL ARM
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
999
WASHER , Replaced By: N000125004319
999
WASHER BRACKET TO SUPPORT
999
WASHER , Replaced By: N000433005304
999
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000125017016
999
WASHER BRACKET TO FRAME
999
WASHER ELBOW FITTING TO PARTITION PANEL
999
LOCK WASHER CONTACT PLATE TO STEERING WHEEL
999
LOCK WASHER REFLECTOR TO BRACKET
999
WASHER BOOT TO CAB FLOOR
999
WASHER BRACKET TO CROSS MEMBER
999
WASHER
999
WASHER , Replaced By: N000433013010
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
NUT , Replaced By: N308675014001
999
LOCK RING STEERING WHEEL HEIGHT ADJUSTMENT,4 188879
999
LOCK RING , 322 UP TO IDENT NO. 036634 EXCEPT FOR 036376,036449,036450,036452-036454 323 UP TO IDENT NO. 006437 328 UP TO IDENT NO. 012103 EXCEPT FOR 011917 L 338 UP TO IDENT NO. 002999 EXCEPT FOR 002938 LP 338 UP TO IDENT NO. 001122 340 UP TO IDENT NO. 000338 EXCEPT FOR 000327,000328
999
LOCK RINGTO 000 553 37 01,000 553 39 01,
999
LOCK RING , UP TO CHASSIS 674067 EXCEPT FOR 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
999
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
999
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
999
LOCK RING AS REQUIRED 1.75 MM
999
LOCK RING ,4 208907
999
LOCK RINGWABCO,5 433388
999
LOCK RINGTO 000 431 94 14,000 431 96 14
999
LOCK RING , Replaced By: A0009949241
999
999
RIVET
999
999
SCREW BRACKET TO SIDE MEMBER, 815770
999
SCREW VALVE TO BRACKET
999
SCREW BRACKET TO BEARING BRACKET
999
SCREW LONGITUDINAL DIFFERENTIAL LOCK VALVE TO BRACKET,5 963747
999
SCREW , Replaced By: N304017006016
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
999
NUT TACHOGRAPH TO BRACKET
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT PULL ROD
999
NUT STRAP TO SUPPORT,5 149419
999
NUT STRAP TO SUPPORT
999
NUT
999
NUT , Replaced By: N308673014001
999
NUT , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
NUT , Replaced By: N308675014000
999
STUD BOLTTO 001 131 52 01
999
STUD BOLT STAY TO BRACKET AND TO SIDE MEMBER M 8X22
999
STUD BOLT
999
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 14X60
999
SCREW BRACKET TO REAR SPRING SADDLE COUNTER PLATE
999
999
SCREW BRACKET TO LEFT SIDE MEMBER
999
PIN
999
PIN , Replaced By: A3619910005
999
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
999
UNION SCREW RELEASE COLLAR LUBRICATION
999
RIVET , UP TO FRONT AXLE 9500154
999
999
TAPPING SCREW LUBRICATING LINE TO SUPPORTING ARM
999
TAPPING SCREW
999
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING SPRING TO JOINT CONNECTION, 083 000189 086 000089 093 000063 183 000202 190 000189
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING FROM POWER STEERING PUMP AT ENGINE TO CUT-IN VALVE
999
SEAL RING LINE CONNECTION
999
SEAL RING , ONLY APPLICABLE TO NOXIOUS-POOR OFFICIAL VEHICLES 911 10/50,20/60 239630 911 12/52,22/62 020730 912 10/50,20/60 084816 912 12/52,22/62 007129
999
SEAL RINGTO 002 430 41 01
999
SHEET METAL SCREW BUZZER TO CAB,4 374617
999
SHEET METAL SCREW , Replaced By: N007971005208
999
SCREW
999
SNAP RING FRONT AXLE STABILIZER
999
GREASE NIPPLE , Replaced By: N071412008102
999
GREASE NIPPLE
999
GREASE NIPPLE
999
GREASE NIPPLE PROTECTIVE TUBE
999
GREASE NIPPLE
999
BULKHEAD FITTING RELEASE BEARING LUBRICATION
999
YOKE POWER CYLINDER TO EXHAUST SHUNT FLAP
999
DOUBLE FITTING
999
DOUBLE FITTING , Replaced By: A0019972872
999
DOUBLE FITTING AT PRESSURE SAFETY VALVE, 023244
999
DOUBLE FITTING FROM PRESSURE REGULATOR TO AIR RESERVOIR
999
DOUBLE FITTING BETWEEN TIRE INFLATOR CYLINDER AND PRESSURE REGULATOR
999
T-FITTING
999
FITTING , Replaced By: A0039972072
999
SCREW PUMP TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
NUT BRACKET TO SIDE MEMBER,K 035196
999
NUT , Replaced By: N308675014002
999
NUT JOINT TO BRACKET
999
NUT RELEASE BEARING LUBRICATION
999
999
HOSE CLAMP. LOOM TIE FUEL LINE, TYPE 1113B UP TO CHASSIS 604683,TYP LP 1517 UP TO CHASSIS 600412,TYPE LP 1317 UP TO CHASSIS 601123,TYPE LP 911 B UP TO CHASSIS601688 CONTINUED,SEE FOOTNOTE 003
999
STRAP165 MM, UP TO CHASSIS 772045 EXCEPT FOR:500000-599999 ORDER BY THE METER
999
PULL ROD LEVER, TO BE ADAPTED DURING ASSEMBLYK 142858
999
PULL ROD BRAKE INTERMEDIATE SHAFT
999
PULL ROD SHIFTING TRANSFER
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
