Поз.
Артикул
Описание
450
SHOCK ABSORBER REAR AXLE
454
GUMMIHULSE. RUBBER MOUNTING TOP AND BOTTOM TO 675 323 06 00
458
GELENKBUCHSE. SPACER TUBE , Replaced By: A0003232750
458
BUSHING BOTTOM TO 673 323 00 00,675 323 06 00
462
SCREW BRAKE ANCHOR PLATE TO STEERING KNUCKLE
462
SCREW SUPPORT TO SIDE MEMBER M 14X120, TO BE ADAPTED DURING ASSEMBLY
462
SCREW ROD TO TRANSFER CASE M 14X75
466
BUSHING , Replaced By: A6673210153
466
SPACER TUBE SHOCK ABSORBER TO FRONT AXLE
470
SCREW , Replaced By: N000960014071, +002N913001014003
470
SCREW , Replaced By: N308765014008
470
HEXAGON HEAD BOLT. SCREW SUPPORT TO SIDE MEMBER M 14X100
474
SCHEIBE. WASHER , Replaced By: A3193260076
474
WASHER SHOCK ABSORBER TO FRAME
474
WASHER SHOCK ABSORBER TO FRAME
478
NUT , Replaced By: N910113014000
478
NUT STEERING SUPPORT TO FRAME
482
COTTER PIN LEVER TO SUPPORT
486
TORSION BAR REAR
490
RUBBER MOUNTING TORSION BAR,REAR
494
BRACKET TORSION BAR,REAR
498
SCREW , Replaced By: N304017008053
498
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
502
SCREW , Replaced By: N304017008021
502
SCREW PIPE CLAMP
506
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
510
NUT
514
CONSOLE LEFT,D 054472
514
CONSOLE TORSION BAR,LEFT,4 282708
514
CONSOLE RIGHT,D 054472
514
CONSOLE RIGHT
518
SCREW END PIECE TO EXHAUST PIPE M 10X25
518
SCREW , Replaced By: N308676014020
518
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
522
RIVET FRAME TRUSS TO SIDE MEMBER
526
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
530
NUT BRACKET TO SUPPORT AND TO END PIECE
530
NUT , Replaced By: N910113014001
530
NUT BRACKET TO SIDE MEMBER
534
SHACKLE ,012818 ONLY REPLACEABLE BY PAIRS THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3093200463
534
SHACKLE TORSION BAR, WITH 90-MM HOLE SPACING TO BE EXCHANGED BY PAIRS
538
RUBBER MOUNTING , Replaced By: A3093200073
538
SPACER TUBE , Replaced By: A3093200073
538
BEARING TORSION BAR BEARING
542
SCREW , Replaced By: N000961012184
542
SCREW , Replaced By: N308676012018
542
SCREW STRUT TO FRAME M 12X62
542
SCREW SHACKLE TO TORSION BAR,5 904661
546
WASHER , Replaced By: N000433013010
546
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
550
NUT , Replaced By: N910113012003
550
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
554
COTTER PIN CYLINDER TO BRACKET
558
SCREW STRAP TO BRACKET
562
NUT , Replaced By: N910113010000
562
NUT STRAP TO BRACKET
999
RUBBER BUFFER AT FRAME, UP TO ENGINE 054188 WITH 110PS(DIN),UP TO ENGINE 142014 WITH 126-130PS(DIN)
