Поз.
Артикул
Описание
10
10
15
GREASE NIPPLE PROTECTIVE TUBE
17
DRIVE FLANGE , FROM IDENT NO. 001675-003341 EXCEPT FOR 001905,001921,001927
17
DRIVE FLANGE
21
UNIVERSAL JOINT CROSS WITH BUSHINGS
21
UNIVERSAL JOINT CROSS , Replaced By: A3854100131
21
23
GREASE NIPPLE
23
GREASE NIPPLE
30
BEARING BUSHING
30
BEARING BUSHING , Replaced By: A3834100042
32
NEEDLE SET124 PIECES, WITH BOOT
34
SNAP RING AS REQUIRED 2.85 MM
34
SNAP RING AS REQUIRED 3.00 MM
34
SNAP RING AS REQUIRED 2.80 MM
34
SNAP RING AS REQUIRED 2.95 MM
34
SNAP RING AS REQUIRED 2.90 MM
50
BEARING RING INTERMEDIATE BEARING NO.1
60
RUBBER MOUNTING INTERMEDIATE BEARING NO.1
65
73
SCREW CONSOLE TO SIDE MEMBER
73
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
77
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
77
WASHER , Replaced By: N000433013010
81
LOCK WASHER FITTING TO BRACKET
83
NUT STRAP TO SUPPORT
90
90
CENTERING FLANGE
94
NUT FOLLOWER FLANGE TO PROPELLER SHAFT TO 384 410 70 30
100
100
PROPELLER SHAFT FROM TRANSFER CASE TO FRONT AXLE 1151 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
110
110
UNIVERSAL JOINT YOKE , WITH BOOT
115
GREASE NIPPLE
115
GREASE NIPPLE PROTECTIVE TUBE
115
GREASE NIPPLE , Replaced By: N071412008102
120
SEAL RING , PROPELLER SHAFT WITH BOOT
130
BOOT
140
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
140
SCREW , Replaced By: A0079901001
140
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
142
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
144
NUT FROM PROPELLER SHAFT TO FRONT AXLE
999
SCREW , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 555708, Replaced By: A3099901501
999
UNIVERSAL JOINT CROSS , Replaced By: A3854100131
999
BEARING BUSHING , Replaced By: A3834100042
999
999
999
999
999
999
