Поз.
Артикул
Описание
5
EXHAUST PIPE FRONT
20
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
24
NUT CONNECTOR TO EXHAUST MANIFOLD
30
BRACKET STEP, TO BE ADAPTED DURING ASSEMBLY
30
BRACKET EXHAUST PIPE TO CROSS MEMBER,5 433230
34
SCREW END PIECE TO EXHAUST PIPE M 10X25
38
NUT , Replaced By: N910113010000
38
NUT STRAP TO BRACKET
45
BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 433229, Replaced By: A3464920319, +001A3464911741
45
BRACKET EXHAUST PIPE,5 433230
50
RUBBER MOUNTING
52
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
54
NUT BRACKET TO SUPPORT AND TO END PIECE
58
CLAMP ATTACHMENT FOR CHARGE AIR PIPE,HOT
62
SCREW REAR EXHAUST PIPE TO MUFFLER
66
NUT , Replaced By: N910113010000
66
NUT STRAP TO BRACKET
100
FRONT EXHAUST PIPE FRONT,REAR PART
105
CLAMP ATTACHMENT FOR CHARGE AIR PIPE,HOT
109
SCREW , Replaced By: N304017010002
109
SCREW BRACKET TO SIDE MEMBER
113
NUT , Replaced By: N910113010000
113
NUT STRAP TO BRACKET
168
EXHAUST MUFFLER ,4 858539
999
SCREW BRACKET TO SIDE MEMBER M 12X40
999
PROTECTIVE PLATE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3464900330
999
BRACKET EXHAUST MUFFLER TO CROSS MEMBER,5 045560
999
CLAMP , Replaced By: A3874900041
