Поз.
Артикул
Описание
154
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
154
BRACKET , Replaced By: A3184923441
156
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
156
SCREW , Replaced By: N308676012012
158
NUT SUPPORT TO SIDE MEMBER
182
BRACKET CABLE HARNESS MOUNTING
182
BRACKET , Replaced By: A0005462243
183
LOOM TIE LINE MOUNTING
184
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
184
BRACKET (PROTECTION AGAINST TORSION),FRONT AXLE
187
SCREW PIPE CLAMP
187
SCREW , Replaced By: N304017008021
190
NUT
191
NUT TWO-WAY VALVE TO BRACKET
192
NUT IN CASE OF SUBSEQUENT INSTALLATION
192
NUT , Replaced By: N304032005005
193
SPRING WASHER ALTERNATOR CONNECTION D+
194
NUT BALL PIVOT TO LEVER
195
SPRING WASHER LICENSE PLATE TO BRACKET
196
BRACKET LINE MOUNTING
196
BRACKET LINE MOUNTING
199
SCREW CLAMP MOUNTING M 6X16
199
SCREW CLAMP MOUNTING M 6X16
199
SCREW , Replaced By: N000000001146
202
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
204
NUT PUMP TO BRACKET
204
NUT , Replaced By: N913004006001
999
BLIND CAPTO A 004 541 48 01
999
SOCKET
999
SOCKETTO 003 542 46 16,99 16
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 27X1
999
GROMMET TACHOGRAPH OR SPEEDOMETER
999
AIR PRESSURE GAUGE
999
ROUND PIN BUSHING REAR "ENR" SOLENOID VALVE BRANCH-OFF 0.75-2.5MM2
999
OIL PRESSURE GAUGE
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PIN BUSHING HOUSING UNIPOLAR
999
PIN BUSHING HOUSING UNIPOLAR
999
TEMPERATURE GAUGE
999
GROMMET
999
ELECTRIC CABLE FROM SPEEDOMETER TO PULSE SENDER UNIT
999
BRACKET , Replaced By: A3604293140
999
WASHER PLUG SOCKET TO INSTRUMENT PANEL
999
BOOT CABLE HARNESS EXTENSION
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 27X1,5 129167
999
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
999
WASHER BRACKET TO AIR INTAKE SCOOP
999
SCREW , Replaced By: N304017008034
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
