Поз.
Артикул
Описание
250
HOUSING CLUTCH
255
BUSHING
260
BUSHING TOP
265
BUSHING TOP
270
FELT RING
275
COVER PLATE
280
BUSHING BOTTOM
285
BUSHING RELEASE SHAFT,BOTTOM
290
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
295
RELEASE SHAFT
300
WASHER AS REQUIRED 1.00 MM
305
FELT RING
310
SPACER WASHER RELEASE SHAFT,BOTTOM
315
LOCK RING RELEASE SHAFT,BOTTOM
320
RELEASE YOKE
320
RELEASE YOKE , Replaced By: A3452930211
325
LEVER LEFT
330
ROLL PIN. CLAMPING SLEEVE
335
WASHER
340
WASHER
345
LEVER RIGHT
350
SPACER TUBE
355
LOCK
360
DISC SPRING WORM TO BRACKET,5 143211 ON VEHICLES HAVING MERCEDES BENZ BODY
362
FITTED WASHER AS REQUIRED 1.5 MM
362
FITTED WASHER AS REQUIRED 2.00 MM
362
FITTED WASHER AS REQUIRED 1.0 MM
365
WASHER GROUND CABLE
370
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
375
SCREW BRACKET TO TRANSMISSION,D 203092
380
LOCK WASHER PROPELLER SHAFT TO REAR AXLES I AND II
385
NUT
390
LOCK WASHERROCKINGER TYP 59 G140,59 G150
395
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
400
LOCK WASHER FITTING TO BRACKET
405
SCREW BELL HOUSING TO TRANSMISSION
410
LOCK WASHER BELL HOUSING TO TRANSMISSION
415
COVER ,079773
420
SCREW CLAMP TO BRACKET
425
NUT
430
SPRING
435
PRESSURE PLATE CLUTCH BRAKE
435
PRESSURE PLATE
440
BRAKE LINING
443
RIVET
445
BRAKE DISC
450
GUIDE
450
GUIDE , Replaced By: A3432540216
455
LOCK WASHER , Replaced By: N912004010102
460
SCREW BRACKET TO SIDE MEMBER
465
SPACER TUBE GUIDE TO BELL HOUSING
470
FRICTION PIECE
475
LOCK WASHER , Replaced By: N912004010102
480
SCREW CLUTCH TO FLYWHEEL
485
RELEASE COLLAR
490
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
495
SEAL RINGTO 000 550 00 83
500
SPRING LOCK RELEASE COLLAR TO RELEASE YOKE
505
RELEASE BEARING
510
HOSE RELEASE BEARING LUBRICATION
510
HOSE RELEASE BEARING LUBRICATION
515
UNION SCREW RELEASE BEARING LUBRICATION
520
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
525
SLEEVE RELEASE COLLAR LUBRICATION
530
LOCK WASHER RELEASE BEARING LUBRICATION
535
NUT BRACKET TO SIDE MEMBER
540
GREASE NIPPLE
540
GREASE NIPPLE FOR SPRING
545
RELEASE LEVER CLUTCH ACTUATION, UP TO CHASSIS 409401 EXCEPT FOR 409120,409131,409154,409203,409350,409358,409366
545
LEVER CLUTCH ACTUATION, FROM CHASSIS 409402 ALSO INSTALLED ON 409120,409131,409154,409203,409350,409358,409366
550
BALL PIVOT RELEASE YOKE
550
BALL PIVOT RELEASE YOKE
550
BALL PIVOT CLUTCH ACTUATION,4 601609
555
WASHER LEVER TO RELEASE SHAFT, WITH L.H.D.FROM IDENT NO. 602167,WITH R.H.D.FROM IDENT NO. 601938
560
SCREW LEVER TO RELEASE SHAFT
565
NUT BRACKET TO RETARDER
570
LOCK WASHER , Replaced By: N912004010102
999
LOCK PLATE CLUTCH PEDAL RESET
999
REPAIR KIT TO 345 250 71 03
999
REPAIR KIT , Replaced By: A3505867025
999
CLUTCH PRESSURE PLATE , Replaced By: A0032502004
999
SCREW , Replaced By: N000085005106
999
HOUSINGTO 001 250 07 04,003 250 20 04
999
RELEASE LEVER CLUTCH ACTUATION
999
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
999
NUT FOR BRACKETS
999
SPINDLE , Replaced By: A0002520616
999
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
999
PRESSURE PLATETO 001 250 07 04
999
FLANGE
999
NUT , Replaced By: A0002523072
999
LOCK FOR BRACKETS
999
HOUSING
999
CLAMP , Replaced By: A0002523227
999
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
999
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
999
BRACKET RELEASE LEVER
999
LEAF SPRING THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
999
PRESSURE PLATE
