Поз.
Артикул
Описание
5
ALTERNATOR , Replaced By: A3441507850
5
ALTERNATOR WITH REGULATOR INCORPORATED AND PULLEY 28V/75A "WAPSA"
5
ALTERNATOR , Replaced By: A3441507450
8
SCREW , Replaced By: A0019906420
8
SCREW , MODEL 343.919.000 FROM ENGINE 154150,MODEL 344.919.000 FROM ENGINE 822957
8
SCREWTO 344 150 73 50
8
SCREWTO 345 150 76 50
11
LOCK WASHERTO 344 150 73 50
14
BALL BEARING FRONT TO 345 150 70 50,345 154 71 01
14
BALL BEARING FRONT AND REAR
17
SEAL RINGTO 005 154 34 02
20
BALL BEARING SLIP RING SIDE TO 004 154 25 02
23
ROTOR
23
ROTORTO 344 150 74 50,78 50
26
COIL , Replaced By: A0001546725
26
COIL EXCITER
26
COILTO 344 150 74 50,78 50
32
RECTIFIERTO 005 154 45 02,006 154 86 02
32
RECTIFIER , Replaced By: A0001545116
32
RECTIFIERTO 344 150 73 50
35
SCREW
38
LOCK WASHERTO 344 150 74 50,78 50
41
BEARINGTO 345 154 71 01
44
CONDENSER
44
CONDENSERTO 345 154 71 01
44
CONDENSER , Replaced By: A0011566701
56
REGULATOR AND CUT-OUT
56
REGULATOR AND CUT-OUTTO 344 150 73 50
59
CARBON BRUSH SETTO 366 150 07 50, 376 150 83 50
59
CARBON BRUSH SET
59
CARBON BRUSH SET , Replaced By: A0001549814
65
SPRING
68
DIODE POS.
68
DIODE , Replaced By: A0015481118
68
DIODE POS.
68
DIODE NEG. TO 344 154 71 01,344 154 72 01, MODEL 343.919.000 UP TO ENGINE 154149,MODEL 344.919.000 UP TO ENGINE 822956
74
SCREWTO 344 150 73 50
77
LOCK WASHERTO 344 150 74 50,78 50
80
SPRINGTO 344 154 71 02
89
MOUNTING KITTO A 345 154 71 01
89
INSULATOR TERMINALS: B+, B-, D+, W TO 376 150 80 50
98
REPAIR KITTO 345 154 71 01
101
WOODRUFF KEY POWER STEERING PUMP
104
FANTO 344 150 74 50
104
FANTO 376 150 80 50,86 50
104
FAN , Replaced By: A3431507074
107
PULLEY ALTERNATOR
107
PULLEYTO 344 150 73 50
110
LOCK WASHER SUPPORT TO SIDE MEMBER
113
NUT PULLEY TO ALTERNATOR
113
NUT BRACKET TO SIDE MEMBER
116
REPAIR KIT ARMATURE MOUNTING
999
REPAIR KIT
999
DIODE , Replaced By: A0005485018
999
BEARINGTO 376 150 80 50
999
COVER
999
BEARING , Replaced By: A0001542449
999
COVER , Replaced By: A0001540767
999
BEARING DRIVE END BEARING
999
BEARING , Replaced By: A0001514149
