Поз.
Артикул
Описание
8
INTAKE MANIFOLD
17
THREADED INSERT ,5 462573
17
THREADED INSERT
65
LINE FROM INTAKE MANIFOLD TO MANIFOLD PRESSURE COMPENSATOR
68
SEAL RING
71
BANJO BOLT. HOLLOW SCREW
77
EXHAUST MANIFOLD
80
FLANGED PIPE SOCKET ,610643
89
BUSHING
92
BUSHING INCLUDED IN REPAIR KIT
116
STUD BOLT BELL HOUSING, FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999 10/20 UP TO IDENT NO. 922885 EXCEPT FOR 502153,502155,502162,502192-502195,502198-502204,502207-599999,918576,921744,921785,921797,922052, 922078,922195,922255,922267,922336,922675,922688,922719,922739,922763,922853. ALSO INSTALLED ON 934036,934433,934539,935068,935169,937098. 50/60 UP TO IDENT NO. 922468 ON 96 KW (130 PS/DIN) 50/60 UP TO IDENT NO. 923153 ON 124 KW (168 PS/DIN)
119
NUT END PIECE TO EXHAUST PIPE
119
NUT CONNECTING PIPE TO EXHAUST BRAKE
128
SHAFT THROTTLE VALVE
131
BALL PIVOT
143
SCREW BRACKET TO AIR CLEANER CONSOLE
146
LOCK WASHER RAIL TO BATTERY SUPPORT
149
SCREW SHAFT TO ELBOW
152
NUT ,123.033 041774,123.053 009521
194
PULL ROD FROM ACCELERATOR CONTROL BRACKET TO REVERSING LEVER 6X250X30/30,D 232778
197
NUT , Replaced By: N304032006004
200
BALL SOCKET CONTROL
203
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
209
LEVER
212
LEVER
218
BALL PIVOT
218
BALL PIVOT , Replaced By: A3129910120
218
BALL PIVOT LEVER
221
GREASE NIPPLE
221
GREASE NIPPLE
227
BRACKET POWER CYLINDER
236
CYLINDER EXHAUST BRAKE KNORR
236
CYLINDER EXHAUST BRAKE WABCO
236
CYLINDER
242
PISTONTO 345 430 73 26
245
SPRING RETAINERTO 345 430 73 26
248
SPRINGTO 345 430 73 26
251
SPRINGTO 345 430 73 26
252
REPAIR KITTO 345 430 73 26
252
REPAIR KIT , Replaced By: A0004305526
252
REPAIR KIT , Replaced By: A0004305526
252
REPAIR KITTO 345 430 00 26
254
HEX. NUT M 12 DIN 934-5 S. NUT , Replaced By: N000934012021
257
BALL SOCKET POWER CYLINDER
293
SPACER TUBE BRACKET AND CYLINDER SIDE COVER TO CRANKCASE
296
LOCK WASHER RAIL TO BATTERY SUPPORT
299
SCREW CLUTCH TO FLYWHEEL M 8X50,838705
302
BRACKET OIL RETURN LINE
305
SCREW CLUTCH TO FLYWHEEL,760271
